3. Dimensions

4. Technical data

Flash energy
Light intensity
Flash frequency
Rated voltage
Voltage range
Current consumption (max)
Power consumption
Duty cycle
Connecting terminals
Ingress protection
Impact strength
Protection class
Operating temperature
Storage temperature
Max. rel. air humidity
Cable inlet
Sealing range of the
feed-through grommet
Housing material
Lens colors
Installation position
Lens colors
09/2021
M20 cutout prepared
12 V DC 24 V DC
10 –15 V 18 – 30 V
DC DC
700 mA 360 mA
7,5 W 9,5 W
0.14 – 2.5 mm² fine stranded / AWG24 - AWG 14 (stranded)
A cable gland with a sufficient degree of protection must be provided when cable
transparent, white, yellow, amber, red, green, blue
Operating instructions PY X-S-05
Drilling pattern inside the housing
5 J
44 cd (clear)
1 Hz
24 V AC
48 V DC
50/60 Hz
40 – 60 V 18 – 30 V
DC AC
170 mA 800 mA
7,5 W 30 VA
100%
IP 66 (EN 60529), Type 4 & 4x
IK08 (EN 50102)
II double insulated equipment
-40 °C...+55 °C
-40 °C...+70 °C
90 %
4x M20 pre-embossed
7 – 13 mm
diameters of < 7 mm are used.
PC/ABS Blend
PC
any
Page 2 / 6
M20 cutout prepared
115 V AC 230 V AC
50/60 Hz 50/60 Hz
92 - 127 V 184– 253 V
AC AC
120 mA 90 mA
14,5 VA 21,5 VA
086200002a
