1. SPECIFICATIONS

1.1 Technical specifications

Parameter
Minimum - Maximum draught
Fuel consumption
Smoke mass flow rate
Performance
Nominal output
Power range
Average CO concentration at 13% of O
NOx concentration at 13% of O
OGC concentration at 13% of O
Particle concentration at 13% of O
Medium draft (trial)
Net weight
Maximum authorized load (fuel)
Reload height
Logs length
Minimum flue height
Ø Flue duct
Ø Air inlet
Front safety distance
Side safety distance
Back safety distance
Average temperature of smoke
Type of combustion
Flue liner
Fuel
Humidity fuel logs
Certification year
Certificate No.:
1.2 Breakdown of delivery components
(
Make sure you have all the components described below in relation to the picture on section II of the ANNEXED document)
1. Fireplace's body.
2. Chimney cap
3. Heat-resistant glove
4. Fire base plates
5. Ceiling plate.
6. Vermiculite deflector
7. Bag with screws and anchors.
8. Floor base plates
9. Cleaning cloth.
10. Documentation bag: output declaration, energy label, guarantee, technical sheet, and installation and operating
characteristics manual.
11. Tool for handling registers and opening doors.
12. Silicone tube.
13. Flue line connector.
14. Metal clamp
15. Heat-resistant spray paint for touch-ups.
1.3 Diagram of the equipment's measurements
See the ANNEXED document, section I
2. REQUIREMENTS PRIOR TO INSTALLATION
ALL LOCAL STANDARDS, INCLUDING NATIONAL AND EUROPEAN REGULATIONS MUST BE COMPLIED WITH UPON
INSTALLATION OF THE EQUIPMENT.
THE INSTALLATION MUST BE PERFORMED BY A PROFESSIONAL. FAILURE TO COMPLY WITH THIS CLAUSE SHALL
EXONERATE THE MANUFACTURER FROM ANY RESPONSIBILITY.
7
2
2
2
2
Value
11-13 Pa
4,34 kg/h
10 g/s
77,5 %
15 kW
10,5 – 18 kW
0,088 %
105 mg/Nm
68 mg/Nm
7,7 mg/Nm
12,1 Pa
325 kg
3,5 kg
200 mm
330 mm
4000 mm
Ø 180 mm
Ø 120 mm
1000 mm
1000 mm
1000 mm
367,3 º C
INTERMITTENT
NOT SHARED
NATURAL WOOD
12-20% - two years under cover
2021
1880-CPR-028-21
3
3
3
