PROTECTION
OVERLOAD Note.5
OVER VOLTAGE
ENVIRONMENT
WORKING TEMP.
WORKING
HUMIDITY
STORAGE TEMP.,
HUMIDITY
TEMP.
COEFFICIENT
VIBRATION
SAFETY & EMC
SAFETY
STANDARDS
WITHSTAND
VOLTAGE
ISOLATION
RESISTANCE
EMI CONDUCTION
& RADIATION
HARMONIC
CURRENT
EMS IMMUNITY
OTHERS
MTBF
DIMENSION
15
105 ~ 160% rated output power; Protection type:
Constant current limiting, recovers automatically after
fault condition is removed
27.6 ~ 32.4V
-20°C ~ +60°C (Refer to output load derating curve)
20 ~ 90% RH non-condensing
-40°C ~ +85°C, 10 ~ 95% RH
±0.03%/ (0 ~ 50) °C)
10 ~ 500Hz, 2G 10min./1cycle, period for 60min.
each along X, Y, Z axes; Mounting: Compliance to
IEC60068-2-6
UL60950-1, TUV EN60950-1 approved, design refer
to EN50178
I/P-O/P: 3 KV AC
I/P-O/P: 100 megohm / 500 V DC / 25 / 70% RH
Compliance to EN55011, EN55022 (CISPR22),
EN61204-3 Class B
Compliance to EN61000-3-2, -3
Compliance to EN61000-4-2, 3, 4, 5, 6, 8, 11,
ENV50204, EN55024, EN61000-6-2, EN61204-3,
heavy industry level, criteria A
1172.3K hr min.
MIL-HDBK-217F (25 )
25*93*56mm (W*H*D)
