HPSPX-2
HOLDING REGISTERS
Data type
33 Start-up timer unsigned int.
34 Kp unsigned int
35 Ti unsigned int. Integration period
unsigned int. Starts auto-tune. Once started cannot
36 Auto-tune function
37 Minimum speed unsigned int. Minimum motor speed (10—50 %)
38 Maximum speed unsigned int. Maximum motor speed (50—100 %)
39
K-factor unsigned int.
40 Output type unsigned int.
Modbus network
41 resistance terminator unsigned int. Sets device as an end device on the line
(NBT)
42
Altitude unsigned int. Current altitude
43
Pitot air velocity unsigned int.
Duct cross sectional unsigned int. Calculation of the Volume Flow Rate when
44
area [ cm ]
2
45
46
Measurement readout unsigned int.
47
unsigned int. Internal voltage source selection for PWM
48 Internal voltage source
49 Recalibrate sensor unsigned int. Sensor recalibration
50 Modbus registers reset unsigned int.
Pour en savoir plus à propos de Modbus sur liaison série, s'il vous plaît visitez:
MIW-HPSPX-2-FR-000 - 24 / 10 / 18
RÉGULATEUR PI POUR
PRESSION DIFFÉRENTIELLE
Description
Start-up period before setting alarm and
span flags. During this period the alarm
and span limits are not compared with the
measured pressure/volume/velocity and
alarm flag and span limit flag registers
remain '0'. Timer is reloaded when
operating setpoint is set to 0 or Auto-tune
function is in progress
Proportional Gain
be aborted.
K-factor according to motor / fan
specifications
Analog / digital output selection
Enables Air Velocity Readout. If '0' air
velocity readout is disabled, if '1' air
velocity readout is enabled and it is
accessible in input register 5. Pitot tube
needed (PSET-PTX-200)
K-factor is not known
Reserved, returns 0
4-digit measurement indication ON / OFF
(the HPSPX-2 does not have a display,
therefore modifying the settings in this
register does not change anything)
Reserved, returns 0
output
Reset Modbus Holding Registers to default
values. When complete this register is
automatically reset to '0'.
http://www.modbus.org/docs/Modbus_over_serial_line_V1_02.pdf
REGISTRES «INPUT»
Les registres «Input» sont en lecture seule. Toutes les données peuvent être lues
par la commande "Read Inputs Registers". Tableau 1 Registres Modbus indique le
type de données retourné et la façon dont il doit être interprété.
REGISTRES «HOLDING»
Ces registres sont lecture / écriture et ils peuvent être gérés avec les commandes
'Read Holding Registers', 'Write single register' et 'Write Multiple Registers'. Les
registres qui ne sont pas utilisés, sont en lecture seule et, par conséquent, écrire
dans ces registres ne rend pas d'échec Modbus, ni apporte des changements.
www.sentera.eu
Retour à la Table des matières
Data
(Voir Table)
(Voir Table)
Default Values
0—1000 60 s 100 =
1—30 5
1—1.000 40 10=
0 =
0
1 =
100—500 200 100 =
500—1.000 1.000 500 =
0—1.000 0
1 =
1—3 1 2 =
3 =
0 = NBT disconnected
0—1 0
1 =
0—5.000 0 1.000 =
0 =
0—1 0
1 =
0 =
0—32.000 0
100
0 =
0—1 1
1 =
0 =
0—1 0
1 =
0 =
0—1 0
1 =
0 =
0—1 0
1 =
100 seconds
10*100 ms = 1s
Inactive
In progress
10 %
50 %
0—10 VDC
0—20 mA
PWM
NBT connected
1.000 m
Disabled
Enabled
Not used
100 cm
2
LED display off
LED display on
3,3 VDC )
12 VDC
Inactive
Active
idle
Reset Modbus
Registers
13 - 14
