5. Connections
sensor
The signal LED indicates the operating status, the Init button
can reset WNM LockNodes (see
LockNodes [} 27]
LockNodes.
)), but has no function with WN
I/O panel
(WN.LN.SENSOR.CABLE)
green (In-Common)

pink (input 1, connection

with green = 1, otherwise
0)
grey (input 2, connection

with green = 1, otherwise
0)
yellow (input 3,

connection with green =
1, otherwise 0)
brown (open collector

output)
white (ground)

Hardware reset of external
