Setting up your router

Setting up your router
You can set up your router via wired or wireless connection.
A. Wired connection
1. Plug your router into a power
outlet and power it on. Connect the
network cable from your computer
to a LAN port on your router.
NOTES:
• Use only the adapter that came with your package. Using other adapters may
damage the device.
Specifications:
•
DC Power adapter
Operating Temperature
Operating Humidity
APAC15866b_RT-AC86U_QSG_172x144mm_V4.indb 5 APAC15866b_RT-AC86U_QSG_172x144mm_V4.indb 5
1
4
Modem
Internet
DC Output: +19V with max. 1.75A current/
+12V with max. 3A current
0~40 o C Storage
50~90% Storage
RT-AC86U
WAN LAN
2
3
Laptop
0~70 o C
20~90%
