Operating- and assembly instruction
Assembly of the carrycot
- (pic.I) Remove the mattress and swing the two clamps (1) till
the stop of the part (2) , which is fixed at the bottom of the
carrycot.
- (pic.II) Close the pushbuttons (3) left, right and at the head
end from the outside. To close the canopy, push the red
buttons (4) and swing it back.
- (pic.III) Place the foot cover (6) over the carrycot and close
the pushbuttons (7) left and right.
Use with one carrycot
- (pic.IV) If you want to use the Twin with a newborn baby and
a child from 9 months, which is already able to sit, you can fix a
single carrycot only on the left side of the frame (in driving
direction)! Remove the seat cover, belly frame and the
canopy on the left (Please have a look to the instruction of the
Twin stroller).
- (pic.V) First fix the small belly frame (8) on the right seat. Bring
it to the right position and lock the clip (9) around the frame
tube.
- (pic.VI) Stick the rear carrycot tube (13) next to the plastic
part over the vertical frame tube in the middle. Now swing it to
the fixation (14) at the left vertical frame tube, it will lock
automatically (audibly).
- (Fig. VII) Now you can push the carrycot onto the two tubes
(8 + 10) from the front. Keep the metal bar (Fig.III, 5) pulled
until the rear bar locks and then use the front two
clamps (12) to press the carrycot down onto the cot's front
tube from above. The clamps will lock automatically. To
remove the cot, pull on the front metal clip (5, Fig. III)
underneath the cot, then pull the cot towards you and off the
frame.
