Napoleon DYNAMIC HEAT CONTROL Manuel D'installation page 19

recessed
WARNING
!
• Shaded components (fi nish framing) must be non-combustible materials.
Dynamic Heat Control™
front air outlet opening
L
M
D
I
note:
Finish framing must be built after appliance has been placed in its fi nal position and venting connected.
This confi guration also requires recess area to use non-combustible facing due to close proximity to
vent.
Recessed volume must be added to the overal size of enclosure.
minimum framing
Ref
I
C
D
H
L
Q*
(Q x R)*
M**
* ONLY APPLICABLE TO OPTION 2, 3 and 5 - Opening must be centered in enclosure on appliance. Dimensions represent
fi nished sizes and where applicable should be adjusted to include fi nish material thickness.
note:
The Elevation series requires a minimum enclosure height (as illustrated) measured from the bottom of the ap-
pliance. For temperature requirements, this area must be left unobstructed. Some venting confi gurations that
require more vertical rise will require a larger enclosure to provide minimum vertical clearance between vent
pipes and combustibles.
fi nish framing - after appliance installation
R
Q
H
C
D
EX36
39 3/4"
43 3/4"
Dynamic Heat Control™
side air outlet opening
L
M
D
22 1/4"
6"
72"
2" min and 3" max
112 sq. in. min.
3", 6" max
R
Q
H
C
D
EX42
45 3/4"
47 3/4"
W415-2753 / 10.23.19
EN
19
