INSTALLATION (continued)

Connecting A/V Equipment

The following are diagrams showing basic instructions for attaching external equipment, like a VCR or
D V D player, t o y o u r TV set. Please refer to operation manuals of external audio/video equipment that will
be connected to your set for additional instructions. PLEASE TURN OFF ALL POWER BEFORE
CONNECTING DEVICES TO EACH OTHER.
Connect VCR's RF OUT terminal to the RF IN jack located on the rear panel of the TV.
VCR

Input from Device to TV

AUDIO/VIDEO OUT
O U T
Audio Cable
(not supplied)
Red White Yellow
Side panel

Output from TV to Device

AUDIO/VIDEO IN
All manuals and user guides at all-guides.com
Coaxial Cable
Video Cable
(not supplied)
White
Red
IN
Rear panel
O U T
White
Red
IN
O U T
IN
Yellow
Red
Rear panel
Rear panel
Note:
DO NOT connect both composite
1 )
(yellow video terminal) and S-Video
terminal. Use only one of the two.
Also, remember to connect the
Yellow audio cables when using S-Video.
2)The side terminals may be easier to
use with a camcorder.
The connections are identical.
7
RF IN
O U T
IN
White
