2.2.1 Operation with 1 solenoid valve
Operation is the same as that for machines with 2 solenoid valves. Obviously, only the RINSE signal parameters will be set
(items 2 and 4 of the menu). To modify the V rinse and T rinse parameters, proceed as described in paragraph 2.1.1 under
RINSE SIGNAL.
If used on dishwashers with one solenoid valve for charge and rinse, connect the RINSE cable to the rinse signal.
Set the T wait time equal to the rinse time of the dishwasher (15-30 seconds). Set the
V Rinse and T Rinse parameters (items 2 and 4 of the menu) as needed.
When the signal is activated on the RINSE cable, the pump doses for the T Rinse time at the V Rinse speed. At this point
the pump waits for the T Wait – T Rinse time. When this time has finished, the pump again detects the presence of the
signal on the RINSE cable and restarts, dosing for the T Charge time at the V Charge speed.

To activate this operation mode, set the T wait time (item 5 of the menu) with values higher than zero, equal to the
dishwasher's rinse time. Recommended time: 15-30 seconds
2.3 PROGRAMMING THE SPEED IN ONLINE MODE
ONLY THE SPEED PARAMETERS can be modified "ONLINE" (without entering programming mode), even while the
pump is running.
To enable this function, scroll to the item 6 in the menu and set it to On, otherwise set it to OFF to disable the function and
save changes upon exiting the menu. (Item set to On by default).
ONLINE modification of the CHARGE speed is accessed by pushing and holding the left key down for at least 2 seconds.
The blinking value representing the CHARGE signal's speed percentage appears on the display
ONLINE modification of the RINSE speed is accessed by pushing and holding the right key down for at least 1 second.
The blinking value representing the RINSE signal's speed percentage appears on the display:
The value can be modified using the UP and DOWN keys and is applied immediately.
If no modification is implemented after at least 4 seconds, you will exit TRIMMER mode.
If CHARGE dosing is underway and RINSE trimmer mode is accessed, the motor goes from the CHARGE speed to the
RINSE speed and changes are immediately applied. After exiting trimmer mode, the motor returns to the CHARGE
parameters. The same is true for RINSE dosing.
2.4

SAVING DATA

To save the settings, scroll the menu using the UP key
returns to standby mode and "
2.5 PASSWORD
The programming menu is accessed from Stand-by by pushing and holding the PROG key for at least 4 seconds; the first
item to appear is P (password) – by entering the correct password it is possible to enter and make changes in the menu.
To change the password scroll the menu up to item o and enter the desired password; this item may vary from 000 to 999
and save changes upon exiting the menu.
2.6 EXITING FROM PROGRAMMING
To exit programming and return to the main menu, scroll the menu using the UP key
display. Now press PROG. The pump returns to standby mode and "
settings are saved.
2.7 STANDBY (FUNCTIONAL STOP)
When the switch is on OFF position, the pump goes on standby.
SbY
The display shows:
From standby, moving the switch back to ON, the pump is reset and dosing starts again, as described in paragraphs 2.1
and 2.2.
The programming menu is accessed from Standby by pushing and holding the PROG key down for at least 4
seconds.
MINI-PRO DD
SbY
" appears on the display. All of the modified settings are active.
0000137164
+
Hld
until " " appears on the display. Now press PROG. The pump
SbY
" appears on the display. None of the modified
rev. 1.0
: c 0 2 0
r 1 0 0
+
Esc
until " " appears on the
