Status Led - i.safe MOBILE IS530.2 Manuel D'utilisation

1
STATUS LED: Display for notifications and charging status.
2
SOS KEY: A long press of the SOS key sends an emergency call to a pre-saved emer-
gency number (only in connection with a Lone Worker Protection app).
3
LOUDSPEAKER
4
POWER KEY: A long press switches the device on/off. A short press switches the stand-
by mode on/off.
5
FRONT CAMERA
6
ISM INTERFACE: Connection for approved accessories. Also see section "Connecting
approved accessories".
7
MAGNETIC CHARGER PORT: Connection for the Magnetic Charger Cable. Also see
section "Charging".
8
SIDE KEY RIGHT: Optional function, e.g. camera - function can be assigned via Button
App (system integrated).
9
CURRENT APPLICATION: Shows all open applications.
10
HOME KEY: Switch to the main screen.
11
BACK KEY: Go to the previous screen.
12
USB INTERFACE: Connection for the USB-C Cable or for connection to other devices.
Also see sections "Charging" and "Connecting approved accessories".
13
MICROPHONE
14
LOUDNESS CONTROL: Volume up/Volume down.
15
SIDE KEY LEFT: Optional function - function can be assigned via Button App (system
integrated).
16
SENSORS: Proximity sensor, light sensor.
17
LED FLASH
18
NOISE CANCELLING: Noise cancelling microphone.
19
LOUDSPEAKER: Loudspeaker for hands-free function.
20
BACK CAMERA
21
BATTERY
EN 7
