Controller Mezon Pro
1 Introduction
MEZON PRO regulators are very powerful controllers for a wide variety of
applications. They come with strong BEC or optocoupler, full JETI Duplex EX
telemetry and programmability of JETI Duplex DS / DC transmitters via the
device manager. All programming steps are in German/English. Even
forward / reverse operation of the motor is possible with this controller. In
addition, the throttle channel can optionally be used from the EX Bus of the
receiver. A separate output pin at the Rx for a throttle channel is therefore
not necessary, telemetry and control signals are transferred to the receiver
via only one cable.
Product description and features
• Compact size
• Setting via the Device Explorer of the JETI DC / DS transmitter
• Real-time Telemetry JETI Duplex EX Bus (perfect for JETI DC / DS transmitters)
• Telemetry data: battery voltage, battery current + BEC current, used battery capacity, RPM, PWM,
controller temperature
• Telemetry data reset by switch from the transmitter
• Powerful BEC, ideal when using JETI Assist or other gyro systems in a model
• BEC with a wide input voltage range and adjustable output voltage
• Activation of the throttle channel from the EX Bus is possible; the receiver then does not have to
offer its own slot for the throttle channel.
• Programmable with JETI Box
• Operating modes: Model aircraft, forward / reverse operation
• Proportional brake with a definable braking point at the throttle stick
• F3A brake conveniently adjustable via the device overview
• Heat sink for long engine run times
• High efficiency
• Firmware upgrade possible
• Wide range of adjustable parameters
