PICO JUKEBOX
Configuration
Commande
clavier 4x4
matrice
Commande par
fermeture de contact
REALITY SYS
LED
1
O
N
1
2
3
4
5
Audio out
1
2
3
4
5
Trigger switches
normalement ouverts
Pico JukeBox V2.3
GUIDE D'INSTALLATION
Remote serial port
1
1 TX out
2 RX in
3 GND
4 Vdc (+)
power
switch
Speakers actifs
On/off switch
ou jumper
GND
DC supply: 5-8V
500mW
Installation 7
