8 - LIMITATION OF THE MAXIMUM ROOM TEMPERATURE
The maximum adjustable value of the temperature setting can be limited as
G
follows:
B
!
turn the knob to the 5 °C mark; then remove the knob (fig. A)
!
extract the JUMPER from its housing (fig. B)
!
Insert the JUMPER in the holes corresponding to the desired temperature (fig. C)
!
replace the knob, making certain it is positioned as before: 5 °C position coinciding
with the index on the front of the case (fig. D).
+
fig. A
8
+
fig. B
Neutral
24 ° 22° 20° 18° 16°
+
fig. C fig. D
