16 iNSPIRE iP3000
Technical Specifi cations
System
45 Hz – 20 kHz ±3 dB
Frequency response
40 Hz – 20 kHz -10 dB
Nominal dispersion 120° H @ -6 dB points
Maximum SPL 130 dB
Crossover type 5 way, active
2 x 308 mm (12") LF driver
Transducers 16 x 88.9 mm (3.5") MF drivers
2 x 25.4 mm (1") HF compression drivers
Limiter Independent high, mid and low frequency
Amplifi er
Maximum output power* 2000 W
Type Class-D
Protection Short circuit, open circuit, thermal
Amplifi er channels 6
Connectors
Input A / B 2 x combo jack / XLR
Sensitivity 4 dBu, nominal
Input impedance 16 kΩ unbalanced, 32 kΩ balanced
Maximum input level +22 dBu
Link output XLR
Mains supply IEC mains connector with integrated power switch
Controls
Hardware Rotary push-encoder
Software iOS/Android interface via Bluetooth
DSP
Factory EQ presets Positioning, sound mode
Display LCD 128 x 32, blue, backlit
Level Main and subwoofer
Equalisation Bass, middle and treble
Protection Lock-out function for all settings
Input Mixer
Equalisation Bass and treble
Reverb KLARK TEKNIK design
Bluetooth Wireless Technology
Frequency range 2402 MHz ~ 2480 MHz
Channel number 79
Version Bluetooth 4.1 dual mode
Output 8 dBm
Compatibility Supports GATT/A2DP 1.2 profi le
Maximum communication range 30 m typical
Connectivity Master-slave: stereo pairing link
Power Supply
Power consumption 180 W @ 1⁄8 max power
Voltage (fuses)
USA / Canada / Japan 100-120 V~, 50/60 Hz (T 10 A H 250 V)
UK / Australia / Europe 220-240 V~, 50/60 Hz (T 5 A H 250 V)
Korea / China 220-240 V~, 50/60 Hz (T 5 A H 250 V)
Enclosure
Dimensions (H x W x D) 2214 x 620 x 620 mm (87.2 x 24.4 x 24.4")
Base 415 x 620 x 620 mm (16.3 x 24.4 x 24.4")
Tower 1011 x 119 x 137 mm (39.8 x 4.7 x 5.4")
Net weight 51.8 kg (114 lbs)
Construction, base 15 mm (5⁄8") plywood
Construction, tower Aluminium alloy
Finish Semi matt black paint
Grille Powder coated perforated steel
Accessories
iP3000-PC Protective cover (available separately)
iP3000-TB Travel Bag (available separately)
iP3000-WHB Wheel Board (available separately)
*independent of limiters and driver protection circuits
Other important information
Important information
1. Register online. Please register your new
MUSIC Group equipment right after you purchase it by visiting
turbosound. com. Registering your purchase using our simple
online form helps us to process your repair claims more
quickly and effi ciently. Also, read the terms and conditions of
our warranty, if applicable.
2. Malfunction. Should your MUSIC Group Authorized
Reseller not be located in your vicinity, you may contact the
MUSIC Group Authorized Fulfi ller for your country listed
under "Support" at turbosound. com. Should your country
not be listed, please check if your problem can be dealt with
by our "Online Support" which may also be found under
"Support" at turbosound. com. Alternatively, please submit an
online warranty claim at turbosound. com BEFORE returning
the product.
3. Power Connections. Before plugging the unit
into a power socket, please make sure you are using the
correct mains voltage for your particular model. Faulty fuses
must be replaced with fuses of the same type and rating
without exception.
