BOXLIGHT MP-650i Manuel D'utilisation

Liquid Crystal Projector
Model
MP-650i
USER'S GUIDE
Thank you for purchasing this LCD projector. Please read this user's manual thoroughly to ensure
correct usage. After reading, store this instruction manual in a safe place for future reference.
Outline
This LCD projector is used to project various
computer signals
NTSC/PAL/SECAM video signals onto a
screen. Little space is required for installation
and large images can easily be realized.
Features
(1) Outstanding brightness
The UHB lamp and high-efficiency optical
system assure a high level of brightness.
(2) Partial magnification function
Interesting parts of images can be magnified for
closer viewing.
(3) Distortion correction function
Distortion-free images are quickly available.
(4) Power zoom and power focus.
(5) P in P function
(6) USB jack
as well as
Contents
Before Use ................................................ 3
Checking the package Contents ................ 8
Names and functions of each part ............ 8
Installation .............................................. 12
Basic operations ...................................... 13
Adjustments and functions ...................... 17
Connection to the video signal
terminals ................................ 22
Connection to the RGB signal
terminal .................................. 22
Connecting to the USB ............................ 25
Connection to the CONTROL signal
terminal .................................. 26
Example of system setup ........................ 31
Cleaning the air filter ................................ 31
.............................................. 32
Lamp
Message table .......................................... 32
Troubleshooting ........................................ 33
Specifications .......................................... 34
About the warranty and
after-service .......................... 35
Page
1
