Parts List
Part No. Qty.
Description
15101
1
Nitro Star T-15 Engine with Pullstart
3797
2
Split 6 Wheel 26mm Chrome
4790
2
X-pattern Radial Tire 26mm D-compound
6122
10
Body Pin (Medium/10pcs)
6154
10
Nylon Strap (3.5x150mm/Black/10pcs)
6163
1
Servo Tape 20x100mm (5pcs)
6274
1
Precut Foam Bumper Gray
6807
2
Shock Shaft 3x31mm (2pcs)
6816
6
Silicone O-Ring S10 (6pcs)
6819
5
Silicone O-Ring P-3 (Red/ 5pcs)
6836
2
Shock Springs 13x29x1.55mm (Black)
50474
1
Silicone Tube 2x5x300mm (Fuel Line)
72001
2
Pilot Shaft 4x30mm(2pcs)
72102
2
Shock Cap 12xM13x0.8mm (2 Pcs/ Purple/ Grooved)
72107
2
Cup Joint 5x10x16mm (2pcs)
72108
1
Cup Joint 5x10x16mm (1pc)
72110
2
Silicone Exhaust Coupling (Purple/2pcs)
72140
1
Air Cleaner Set
72144
1
Linkage Set
72148
1
Brake Cam Shaft/Plate Set
72157
1
Arm Brace Set
72161
1
Nitro MT 2 Speed Gear Shaft
73913
1
Main Chassis 2.5mm (Aluminum/Purple)
76817
1
Spur Gear 47T (1M)
76822
1
Spur Gear 52T W/ Collar Set (Only use the Collars)
76843
1
Spur Gear 43T (1M)
76978
1
Threaded Pinion Gear 18T x12mm (1M)
76982
1
Threaded Pinion Gear 22T x12mm (1M)
85029
1
Radio Tray Set
85030
1
Suspension Arm Set
85031
1
Shock Tower/ Bumper Set
85032
1
Body Post/ Link Set
85033
1
Support Set
85036
1
Gearbox Set
85037
1
Rear Hub Set (2 Degree/ 1 Degree)
85038
1
Front Upright Set (8 Degree/ 10 Degree)
85039
1
50/50 Servo Horn Set
86014
1
Gear Diff Bevel Gears (13T and 10T)
86016
1
Gear Diff O-ring Set
86021
1
Flywheel (with Collet and Pins)
86022
1
Collet 6x10mm
86023
1
Center Dogbone 6x60mm
86036
2
Dogbone 6x52mm (2pcs)
86037
1
Aluminum Exhaust Header (Black)
86039
1
Threaded 2-Speed Clutch Bell 12mm
86050
1
2-Speed Maintenance Set
87021
1
Fuel Tank With Primer (75cc)
87022
1
Foam Tape Strip 25x60mm
87023
1
Gear Diff Adjustment Spring
87028
1
Teflon Clutch Shoe and Spring Set
93317
2
Turnbuckle 4-40x 34mm
A249
4
Ball M2x3.8x4.5mm
A280
2
Flange Shaft Set 3x25mm/A284 3x30mm
A281
2
Flange Shaft Set 3x36mm/A282 3x42mm
A396
1
Servo Saver Set
Set Parts
Part No. Qty.
Description
86038
1
2 Speed Transmission (Nitro 3)
Option Parts
Part No. Qty.
Description
3795
2
Split 6 Wheel 26mm (White)
3796
2
Split 6 Wheel 26mm (Black)
3797
2
Split 6 Wheel 26mm (Chrome)
3798
2
Split 6 Wheel 26mm (Gold)
6751
2
Pro Linear Spring 13x25mm (Orange 345g/mm)
6753
2
Pro Linear Spring 13x25mm (Yellow 392g/mm)
6754
2
Pro Linear Spring 13x25mm (Red 432g/mm)
6756
2
Pro Linear Spring 13x25mm (Green 480g/mm)
6757
2
Pro Linear Spring 13x25mm (Blue 493g/mm)
6759
2
Pro Linear Spring 13x25mm (Pink 540g/mm)
6833
2
Shock Springs 13x29x1.4mm (White)
6834
2
Shock Springs 13x29x1.45mm (Yellow)
6835
2
Shock Springs 13x29x1.5mm (Red)
6836
2
Shock Springs 13x29x1.55mm (Black)
6837
2
Shock Springs 13x29x1.6mm (Green)
6838
2
Shock Springs 13x29x1.65mm (Blue)
6839
2
Shock Springs 13x29x1.7mm (Purple)
72170
2
Threaded Aluminum Shock Set (45-56mm)
72175
1
High Performance Air Cleaner
72213
2
Heavy Duty Diff Shaft (2pcs/ Gear Diff)
72215
1
Gear Diff Adjustment Spring Set(Med. Firm. Stiff)
72223
1
Titanium Turnbuckle Set
72228
1
Stainless Steel Suspension Shaft Set w\ Rear Brace
72230
1
Slipper Clutch Set (use w/ 47T Spru Gear and single speed pinion)
72525
1
Racing Fuel Tank (75cc)
Part No. Qty.
Description
A431
1
Diff Case
A471
2
Shock Parts Set
A540
2
HPI Sports Shock Body (45-56mm/ 2pcs)
A556
2
Axle 5x32mm (Front/ 2pcs)
A557
2
Axle 5x38mm (Rear/ 2pcs)
A558
2
Differential Shaft (2pcs)
A559
1
Gear Shaft 5x37mm (1pc)
A783
4
Ball 4.7x14mm (Purple Anodized)
A805
1
Pilot Shaft M5
A838
4
Flange Pipe 3x4.5x5.5mm
A855
1
Diff Final Gear Set (P1x38T/ P1x13T)
A868
1
Tuned Pipe (Composite Nylon)
A875
5
Exhaust Gasket
A880
1
Clutch Bell Set (2-Speed w/ Pin & Bearing)
A881
1
Clutch Holder For Nitro RS4 2 Speed
A882
1
Heavy Duty 1st Gear Adapter
A896
1
Throttle Linkage Set
B021
2
Ball Bearing 5x10x4mm
B022
2
Ball Bearing 5x11x4mm (2pcs)
B030
2
Ball Bearing 10x15x4mm (2pcs)
Z125
14
Ball Cup (14pcs)
Z136
4
Ball End 4-40 (Black)
Z150
1
Antenna Pipe Set
Z164
1
Heavy Weight Grease (#30000/ Gear Diff)
Z170
1
Silicone Shock Oil #300
Z224
10
Washer M3x8mm (Black)
Z238
4
C-Clip 13mm (4pcs)
Z242
20
E Clip E2mm (20pcs)
Z251
10
Spring Pin 1.5x8mm
Z264
10
Pin 2x10mm Silver (10pcs)
Z282
4
Step Screw M3x14mm (4pcs)
Z509
6
Button Head Screw M3x30mm
Z517
10
Binder Head Screw M3x8mm (10pcs)
Z526
6
Flat Head Screw M3x8mm (6pcs)
Z527
6
Flat Head Screw M3x10mm (6pcs)
Z543
6
Cap Head Screw M3x10mm (6pcs)
Z561
6
Tp. Flanged Screw M3x10mm
Z567
10
Tp. Binder Head Screw M3x10mm (10pcs)
Z568
10
Tp. Binder Head Screw M3x12mm (10pcs)
Z569
10
Tp. Binder Head Screw M3x15mm
Z578
10
Tp. Flat Head Screw M3x12mm (Black)
Z581
10
Tp. Flat Head Screw M3x18mm (10pcs)
Z593
4
Screw Shaft 3x27mm
Z599
4
Screw Shaft 3x40mm
Z653
6
Nut M3 (6pcs)
Z662
2
Lock Nut M2 (4pcs)
Z684
4
Flanged Lock Nut M4 (4pcs)
Z694
10
Washer M5x10x0.5mm (Silver)
Z699
6
Washer 7x12x0.8mm (Black/ 16pcs)
Z721
4
Set Screw M4x4mm
Z903
1
Allen Wrench 2.5mm
Z904
1
Allen Wrench 2.0mm
Z950
1
Cross Wrench (Small)
Z960
1
Turnbuckle Wrench
Part No. Qty.
Description
A770
2
HPI Sport Shock Set
Part No. Qty.
Description
73047
1
Front Shock Tower (Woven Graphite)
73048
1
Rear Shock Tower (Woven Graphite)
73056
1
Upper Deck (Woven Graphite)
73914
1
Super Chassis (3mm 7075)
76815
1
Spur Gear 45 Tooth (1M)
76977
1
Aluminum Threaded Pinion Gear 17Tx12mm (1M)
76979
1
Aluminum Threaded Pinion Gear 19Tx12mm (1M)
76981
1
Aluminum Threaded Pinion Gear 21Tx12mm (1M)
76983
1
Aluminum Threaded Pinion Gear 23Tx12mm (1M)
80803
2
MIP Shiny Cvds Front (2pcs/200mm)
80804
2
MIP Shiny Cvds Rear (2pcs/200mm)
86122
1
Front One-Way Differential
A111
2
Super Shock Set (45-56mm)
A209
1
Sway Bar Set
A445
1
Spur Gear 39 Tooth (1M)
A447
1
Spur Gear 41 Tooth (1M)
A844
1
Fiber Brake Disk
A863
2
Engine Mount (HPI OS)
A885
1
Nitro Racing Clutch
A889
1
Slide Carb Throttle Linkage Set
A915
2
Heat Sink Engine Mount (20mm) For Pull Starter
A920
2
Heat Sink Engine Mount (15mm) Non-pull Starter
A925
1
Light Weight Flywheel (40mm) For Pull Starter
A926
1
Light Weight Flywheel (32mm) Non-pull Starter
A958
1
Ball Diff Set
Z679
5
Wheel Nut M4 (Purple/5pcs)
45
