7. Pump groups DN40 / DN50 / DN65
Embodiment FL-MK
DN 40 (1 1/2")
without pump
without pump, with pump cut-out*
Grundfos-pump MAGNA3 40-100 F
Wilo-pump Stratos 40/1-4
Wilo-pump Stratos 40/1-8
Pump dimension 250 mm
DN 50 (2")
without pump
without pump, with pump cut-out*
Grundfos-pump MAGNA3 50-100 F
Wilo-pump Stratos 50/1-8
Wilo-pump Stratos 50/1-10
Pump dimension 280 mm
DN 65 (2 1/2")
without pump
without pump, with pump cut-out*
Grundfos-pump MAGNA3 65-120 F
Wilo-pump Stratos 65/1-12
Pump dimension 340 mm
*For selected pumps made by Grundfosand Wilo.
7.3 Technical data FL-UK and FL-MK
Technical data Pump groups FL-UK
DN
top connection
Bottom connection
Pump
Axis-Centre distance
Components made from
Dimensions
Sealant materials
Temperature display
Operating temperature
Operating pressure
k – value
VS
47
Art. no. Connection
mit Isolierung
66547 EA DN 40 / AD = 48,3
66547 EAS DN 40 / AD = 48,3
66547.21 DN 40 / AD = 48,3
66547.14 WI DN 40 / AD = 48,3
66547.16 WI DN 40 / AD = 48,3
66548 EA DN 50 / AD = 60,3
66548 EAS DN 50 / AD = 60,3
66548.21 DN 50 / AD = 60,3
66548.12 WI DN 50 / AD = 60,3
66548.13 WI DN 50 / AD = 60,3
66549 EA DN 65 / AD = 76,1
66549 EAS DN 65 / AD = 76,1
66549.22 DN 65 / AD = 76,1
66549.12 WI DN 65 / AD = 76,1
40
Victaulic ø 48,3 Victaulic ø 60,3
Victaulic ø 48,3 Victaulic ø 60,3
steel, brass, EPS insulation
approx. h 920 x w 500 x d 350 mm
14,5
50
Victaulic ø 76,1
Victaulic ø 76,1
as per list
250 mm
approx. h 1000 x w 500 x d 350 mm
EPDM
0 to 120 °C
up to 110 °C
PN 10
20,5
Height
920 mm
920 mm
920 mm
920 mm
920 mm
920 mm
920 mm
920 mm
920 mm
920 mm
1000 mm
1000 mm
1000 mm
1000 mm
65
26
