NOTE
According to the applicable product liability laws,
the manufacturer of the device does not assume lia-
bility for damages to the product or damages caused
by the product that occurs due to:
Improper handling no complied with the operat-
f
ing instructions.
Repairs by third parties and not by authorized ser-
f
vice technicians.
Installation of non-original spare parts.
f
Non-intended use.
f
Electrical system breakdown due to power of the
f
machine in a manner not compliant with the elec-
tric and VDE regulations.
TECHNICAL DATA
Article Number
Model
Rated voltage
Rated frequency
Phase
Maximum operating pres-
sure
Maximum flow rate
Thermal capacity
Outlet water temperature
Absorbed power
Motor poles
Motor working speed
Fuel tank capacity
Fuel consumption
Detergent tank capacity
Discalling tank capacity
High pressure hose length
Power cable length
Sound pressure level (LpA)
Sound power level (LwA)
Uncertainty (K)
Dimensions (LxWxH)
Net weight
46 424
PWH 140 PLUS
V
230/240
Hz
50
Ph
1
bar
140
l/h
450
kW
26
°C
60
kW
2,4
No
2
rpm
2.800
l
4
kg/h
1,9
l
0,5
l
-
m
8
m
6
dB(A)
82
dB(A)
96
dB
2
cm
64x48x76
kg
47
IDENTIFICATION (Fig 1)
1. Transport handle
2. Hose reel handle
3. Transport wheel
4. On-Off switch
5. Fuel tank cap
6. High pressure lance
7. High pressure hose
8. Water outlet
9. Water inlet
OPERATION
PREPARING THE UNIT
Unpacking and completing the assembly should
be done on a flat and stable surface, with enough
space for moving the machine and its packaging,
always making use of suitable equipment.
All the fundamental parts and safety devices of
the machine are assembled by the manufacturer.
For reasons of packing and transport, some sec-
ondary parts are supplied separately. The user
must fit these parts as explained in the instruc-
tions supplied in each assembly kit (Fig. 2, 3).
FUELING AND LUBRICATION
In the hot water high pressure cleaners a diesel
fuel burner is used for water heating.
Fuel specifications: Diesel for motors.
WARNING
Never smoke whilst refueling and keep fuel away
from all sources of fire or spark. Avoid inhaling the
fuel fumes and always refuel in outside and well ven-
tilated areas.
To fill the fuel tank (Fig. 4):
1. Remove the fuel tank cap (Fig. 1.5).
WARNING
Carefully open the tank top as pressure could
have formed inside.
2. Add fuel to the upper level of the fuel tank.
Leave a minimum 5mm of space between the
top of the fuel and the inside edge of the tank
to allow for expansion.
3. Reposition the fuel tank cap and tighten appro-
priately.
WARNING
Attempting to use the cleaner without fuel may
cause damage to the fuel pump.
SAFETY DEVICES
The safety devices protect the user and the appli-
ance. The machine is factory set and all its safety
devices are sealed. It is forbidden to alter their ad-
justment values. They must not be tampered with
or used for other than their designated purpose.
Safety valve to protect the high pressure hy-
draulic circuit in the event of a by-pass valve mal-
function or if the hydraulic circuit is blocked. The
safety valve is calibrated by the manufacturer and
sealed. Operations involving the safety valve must
be performed by a technical service center only.
Safety device on lance handgrip to prevents the
trigger on the handgrip from being operated ac-
cidentally.
