8. To clamp the awning frame firmly be-
tween the ceiling and the floor, turn the
threads of the foot caps
– clockwise to extend the feet (Fig. 15).
– anticlockwise to shorten the feet
(Fig. 15).
9. Using the screws (19) and (20), screw
the extensions (7) and (8) to the down-
pipe (22) that has been inserted through
the lower seam of the awning canopy
(Fig. 16).

Adjusting the height

1. To change the height of the canopy
pole, loosen the screws on the plastic
clamps (25), without unscrewing them
completely (Fig. 17).
2. Slide the canopy pole (24) upwards until
you reach the desired height. Make sure
that the canopy pole remains horizontal
(Fig. 17).
3. Tighten the plastic clamps again (Fig. 17).
4. To change the height of the awning frame,
read Step 8 in chapter "Awning frame"
(Fig. 18).

Adjusting the tilt

The awning must be extended to adjust the
tilt angle.
1. Loose the screws on the fixing rings (26).
Do not completely unscrew them.
2. Slide both fixing rings (26) to the desired
height. Make sure that the fixing rings
are mounted at the same height and that
the extensions do not touch the ceiling
when the awning is retracted or extended
(Fig. 19).
3. Screw the fixing rings tight again.
Before retracting the awning, push the
fixing rings down far enough to ensure
that the extensions do not touch the
ceiling when retracting. Make sure that you
tighten the fixing rings at the same height to
make sure the awning canopy is always tight-
ly rolled up. You can adjust the tilt angle again
the next time you use the product.
Assembly Page EN-7
