RF Rx SW868/SW915/SW917/SW922-1W 24VAC/DC
//
Montage- und Anschlussanleitung / Funkempfänger
Mounting and wiring instructions / Wireless receiver
Instructions de montage et de câblage / Récepteur sans fil
Istruzioni di montaggio e collegamento / Ricevitore wireless
Instruções de montagem e instalação / Receptor sem fio
Инструкция по монтажу и подключению / Радио-приемник
English
as the normative requirements of the machine manufacturer. In case
of doubt, the German language version of these instructions shall
prevail.
Scope of delivery
1 device, 1 mounting and wiring instructions, carton.
Intended use
The one channel radio receiver is used to switch electrical loads via
radio transmission. The transmitters must conform to the steute Wire-
less protocol of the LR and ULR modules. The output of the receiver
can be switched by a maximum of 10 transmitters. Therefore, each
transmitter must be taught in once.
Mounting and wiring
The wireless range depends heavily on the local conditions. Conductive
materials may strongly affect the radio signal. This also includes thin
foils, e.g. aluminium laminations on insulation materials.
Antenna
Use suitable antennas only:
Device
Antenna
RF magnet antenna 5dBi
SMA plug-in connector
straight 1.5 m
SW868/922
RF magnet antenna 2dBi
SMA plug-in connector
straight 2 m
RF magnet antenna 5dBi
R-SMA plug-in connector
straight 3.6 m
SW915/917
RF magnet antenna 2dBi
R-SMA plug-in connector
straight 2 m
Mount the antenna on a metal plate. The metal plate serves as HF
counterweight. Minimum size of metal plate: 250 x 250 mm. Observe
minimum sideways distance to nearest wall or disturbance source:
300 mm. Do not bend or clamp the cable. Minimum bending range of
cable: >15 mm.
Allocation of locations and radio frequencies:
Device type Radio frequency
SW868
868.3 MHz
SW915
915.0 MHz
SW917
917.0 MHz
SW922
916.5 MHz
Mat. No.
1188958
1470770
1188987
1470773
Place of use
according to
EU
2014/53/EU (RED)
USA
FCC
Canada
IC
Mexico
IFT
Brazil
ANATEL
Japan
ARIB STD-T108
Design of wireless range
The radio signal is attenuated on the way from the transmitter to
the receiver. In addition, the radio signal is attenuated/influenced by
obstacles. The degree of attenuation depends on the material of the
obstacle. The following tables serve as a guide.
Penetration of radio signals:
Material
wood, gypsum, glas uncoated
brick stone, press boards
armoured concrete
metal, aluminium lamination, water
Typical ranges:
Place of use
in free field (SW868/915/917 LR)
in free field (SW868/915/917 ULR)
in free field (SW922 LR)
in free field (SW922 ULR)
indoors (SW868/915/917 LR)
indoors (SW868/915/917 ULR)
indoors (SW922 LR)
indoors (SW922 ULR)
To get the maximum range: use the specified antennas. With other an-
tennas, the maximum range may differ.
Safety
Do not use the device in connection with other devices whose direct or
indirect purpose is to ensure life or health, or whose operation may
pose a threat to humans, animals or material assets.
N.B.
The electrical connection may only be carried out by authorised per-
sonnel. Subject to technical modifications. The described products
were developed in order to assume functions as part of an entire plant
or machine. It is the responsibility of the manufacturer of a plant or
machine to guarantee the correct general function. steute does not as-
sume any liability for recommendations made or implied by this de-
scription. New claims for guarantee, warranty or liability cannot be de-
rived from this document beyond the general terms and conditions
of delivery.
Start-up
Requirements
- Mount device on standard DIN rail.
- Connect cable for supply voltage 24 VAC/DC.
- A maximum of 10 switches can be taught in parallelly.
- The LEDs show the operating states. After switching on the receiver,
the orange LED 1 flashes if no switch has been taught in. If the or-
ange LED 1 does not flash, switches have already been taught in.
3 / 20
Penetration
90...100 %
65...95 %
10...90 %
0...10 %
Wireless range (approx.)
450 m
700 m
150 m
230 m
40 m
50 m
20 m
25 m
