RF 10 SW868/SW915/SW917/SW922
//
Montage- und Anschlussanleitung / Funkschalter
Mounting and wiring instructions / Wireless switch
Instructions de montage et de câblage / Interrupteur sans fil
Istruzioni di montaggio e collegamento / Interruttore wireless
Instruções de montagem e instalação / Interruptor sem fio
Инструкция по монтажу и подключению / Радио-выключатель
Deutsch (Originalbetriebsanleitung)

Entsorgung

- Nationale, lokale und gesetzliche Bestimmungen zur
Entsorgung beachten.
- Materialien getrennt dem Recycling zuführen. Eventuell enthaltene
Batterien fachgerecht entsorgen.
Hinweise
Technische Änderungen vorbehalten. Umbauten und Veränderungen
am Gerät sind nicht gestattet. Die hier beschriebenen Produkte wur-
den entwickelt, um als Teil einer Gesamtanlage oder Maschine sicher-
heitsgerichtete Funktionen zu übernehmen. Es liegt im Verantwor-
tungsbereich des Herstellers einer Anlage oder Maschine, die korrek-
te Gesamtfunktion sicherzustellen. steute übernimmt keine Haftung
für Empfehlungen, die durch diese Beschreibung gegeben oder impli-
ziert werden. Aufgrund dieser Beschreibung können keine neuen, über
die allgemeinen steute-Lieferbedingungen hinausgehenden, Garan-
tie-, Gewährleistungs- oder Haftungsansprüche abgeleitet werden.
ESD
Bei allen Arbeiten, die das Öffnen des Gerätes erforderlich machen,
auf ausreichenden ESD-Schutz achten.
English
Use of the mounting and wiring instructions
Target group: authorised and qualified staff.
All actions described in these instructions may only be performed by
qualified persons who have been trained and authorised by the
operating company.
1. Read and understand these mounting and wiring instructions.
2. Comply with the valid occupational safety and accident prevention
regulations.
3. Install and operate the device.
Selection and installation of devices and their integration in control
systems demand qualified knowledge of all the relevant laws, as well
as the normative requirements of the machine manufacturer. In case
of doubt, the German language version of these instructions shall
prevail.
Scope of delivery
1 device, 1 battery, 1 mounting and wiring instructions, carton.
Intended use
The one-channel wireless switch is used to switch electrical loads
via radio transmission. The receiver must support the protocol of the
sWave® wireless technology.
Allocation of locations and radio frequencies:
Device type Radio frequency
SW868 868.3 MHz
SW915 915.0 MHz
SW917 917.0 MHz
SW922 916.5 MHz
Mounting and wiring
Mount the device on an even surface. Install the device according to
the mounting and wiring instructions of the receiver. The wireless
range depends heavily on the local conditions. Conductive materials
may strongly affect the radio signal. This also includes thin foils, e.g.
aluminium laminations on insulation materials.
Design of wireless range
The radio signal is attenuated on the way from the transmitter to
the receiver. In addition, the radio signal is attenuated/influenced by
obstacles. The degree of attenuation depends on the material of the
obstacle. The following tables serve as a guide.
Penetration of radio signals:
Material
wood, gypsum, glas uncoated
brick stone, press boards
armoured concrete
metal, aluminium lamination, water
Typical ranges:
Place of use
in free field (SW868/915/917)
in free field (SW922)
indoors (SW868/915/917)
indoors (SW922)
Field strength meter for range test:
Transmitter Device
SW868 swView 868 MHz
SW915 swView 915 MHz
SW917/SW922

Radio operation

The transmission of a switching command from the transmitter to the
receiver takes about 80 to 100 ms, based on the sWave® data trans-
mission. The switching signal from a transmitter may not be generated
at a shorter interval, otherwise the signal will be suppressed.
2 / 16
Place of use according to
EU 2014/53/EU (RED)
USA FCC
Canada IC
Mexico IFT
Brazil ANATEL
Japan ARIB STD-T108
Penetration
90...100 %
65...95 %
10...90 %
0...10 %
Wireless range (approx.)
450 m
150 m
40 m
20 m
Material No.
1190393
1221794
on request
