Minox X-range Mode D'emploi page 16

Changing the reticle
Default setting: Circle
Two reticles are available to aim with while measuring - a cross
or a circle. First enter the menu mode. Press the measuring but-
ton to switch alternatingly between the cross and circle. Press
the menu button to confirm your selection. The menu will then
automatically jump to the next menu item.
Select measuring unit
Default setting: Meter
Two distance measuring units are available - meters and yards.
You can select one or the other by pressing the measuring but-
ton. Press the menu button to confirm your selection. The menu
will then automatically jump to the next menu item.
Reticle brightness
Default setting: Level 3 of 5
The display can be adjusted in 5 brightness levels. The respec-
tive level is shown as a number in the display. Press the meas-
uring button to select the desired brightness.
30 30
Distance measuring options
Default setting: Standard
You have 3 modes for measuring distances - Last (L) Best (B)
and Standard (Std).
Last (L) setting:
Measurement reading
In this setting, the distance to the object that is furthest from
your location is displayed. An example: You are trying to meas-
ure the distance to an object that is very far away. While you
are measuring, there are trees or other obstacles between you
and the object. You will see the distance to the furthest object
that could be measured (your target). An "L" will appear in the
display.
Setting Best:
Measurement reading
In this setting, the distance to the object that is closest to your
location is displayed. An example: You are trying to measure
an object which is in front of trees and shrubs. You will see
the distance to the closest object that could be measured (your
target). An "B" will appear in the display.
Standard setting:
Measurement reading
In this setting, you will always be given the exact distance to
the object that is in the centre of the reticle at the moment in
which the measurement is being made. For example: You try to
measure the distance to an object that is between some trees.
Due to some shaking of the binoculars while you are meas-
uring, you may have to take several measurements until the
distance to your object has been correctly determined. Due to
your shaking, it is possible that you might have inadvertently
measured the distance to trees surrounding your target.
Options for measuring angles:
Default setting: Off
There are 3 modes available for measuring angles. Off (OFF),<
(angle) and EHD (equivalent horizontal distance).
Setting Off:
Measurement reading
In this setting, only the distance in the direct line of sight to the
object is displayed.
Setting <:
Measurement reading
In this setting, the distance in the direct line of sight to the
object is indicated in the upper part of the display. The angle
of the measurement is indicated in the lower part of the dis-
play. An example: If you are in the mountains and measure the
distance to an object that is above you, you can read the incli-
nation angle here.
