Operation - Hoover BH90200 Guide De L'utilisateur

WARNING:
Do not attempt to modify this product or create accessories not
recommended for use with this product. Any such alteration or modification is misuse
and could result in a hazardous condition leading to possible serious personal injury.
Spray Wand Connection
1� Insert the spray wand into the handle as
shown�
2� Slide the o-ring down until it touches the
handle�
3� Install the threaded coupler onto the handle
and tighten securely�
4� Rotate the nozzle until it is aligned with the
handle (pointing down) and ready for use�
5� Slide the nut onto the threaded coupler and
tighten securely�
6� Pull on the spray wand to be certain it is
properly secured�
7� Place the assembled handle into the handle storage area�
How To Connect the Hose
1� To attach the hose to the tank:
2� Slide the nut on the hose away from the hose end�
3� Insert the hose end into the hose connector as
shown� Make sure the connection is secure�
4� Slide the nut over the opening and hose end�
Hand tighten� Do not overtighten�
To attach the hose to the handle: The hose
comes preassembled to the handle� If it is loose,
follow the instructions below�
1� Install the threaded coupler onto the handle
and tighten securely�
2� Slide the nut on the hose away from the hose end�
3� Insert the hose end into the opening on the threaded coupler� Make sure the connection
is secure�
4� Slide the nut over the hose and threaded coupler� Hand tighten� Do not over-tighten�
How To Connect the Shoulder Harness
To prevent back and shoulder fatigue, always use the
quick release shoulder harness when operating this
tool� If your back or shoulders become sore, take a
break and then adjust the position of the harness�
1� Squeeze and hold the latch on the spring clip�
2� Place the spring clip onto the strap hanger and
release the latch�
3� Repeat to secure second spring clip�
4� Place the strap around your shoulder and adjust it to
a comfortable position�
4

OPERATION

WARNING:
WARNING:
Always wear eye protection with side shields or goggles marked to
Do not allow familiarity with the product to make you careless.
comply with ANSI Z87.1. Failure to do so could result in fluids entering your eyes
Remember that a careless fraction of a second is sufficient to inflict serious injury.
resulting in possible serious injury.
WARNING:
Use safety equipment. Protect your eyes, skin, and lungs while
mixing, filling, spraying, and cleaning. Failure to do so may result in serious personal
injury and damage to property.
NOTICE: Before each use, inspect the entire product for damaged, missing, or loose parts
such as screws, nuts, bolts, caps, etc. Tighten securely all fasteners and caps and do not
operate this product until all missing or damaged parts are replaced. Please contact
customer service or an authorized service center for assistance.
What Solution Can You Use?
You may use this product for the purpose listed below:
• For use with most consumer grade home and garden chemicals such as insecticides,
fungicides, weed killers, and fertilizers
DO NOT USE THIS SPRAYER WITH BLEACH, HYDROGEN PEROXIDE, PINE SOL OR PINE OIL
BASED SOLUTIONS. DO NOT USE WITH VINEGAR.
WARNING:
c
If this product is used for herbicide/insecticide applications do not
re-purpose it for use with disinfectants. Obtain a second nozzle set and tool for
dedicated use with disinfectants only. Tools used for herbicide/insecticide applications
are regulated under EPA Federal Insecticide, Fungicide, and Rodenticide Act regulations
and are considered contaminated.
Filling the Tank
WARNING:
Always follow the chemical manufacturer's instructions printed on
their product labeling for use, cleaning, and stor¬age. Clean thoroughly after each use,
following the instruc¬tions in the Maintenance section of this manual. Chemicals should be
stored out of the reach of children. Failure to do so may result in serious personal injury.
• Liquids used must be as thin as water. Thicker liquids will not spray properly.
• Do not overfill the tank.
NOTE: If using a measuring container or funnel to fill the tank, be sure to thoroughly
clean and rinse these items after use� If premixing the spraying solution, rinse the
container used for mixing�
TO FILL:
1� Remove the battery pack�
2� Unscrew the measuring cap and remove it from the tank�
3� Fill the tank with the desired amount of water (up to 2 gallons)�
4� Measure the recommended amount of liquid� The measuring cap may be used for
measuring up to 4 oz�
