QFX R-180 Mode D'emploi

OPERATION INSTRUCTION
-,�-----------
FUN CT 1O NA L DESCRIPTION
FM BAND RECEIVER
OFX
R-180
A
The Lightning flash
and
arrowhead
within the triangle is
'
sign
warning
alerting you of
" dangerous voltage "
inside the product.
I. Do not install this equipment in a confined or building-in space such as a book case or similar unit,
and remain a well ventilation conditions at open site. The ventilation should not be impeded by
covering the ventilation openings with items such as newspaper, table-cloths, curtains etc.
2. WARNING : To reduce the risk of fire or electric shock, do not expose this apparatus to rain or
moisture. The apparatus shall not be exposed to dripping or splashing and that objects filled with
liquids, such as vases, shall not be placed on apparatus.
3. WARNING: The battery (battery or batteries or battery pack) shall not be exposed to excessive heat
such as sunshine, fire or the like.
4. WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily
operable
5. No naked flame sources, such as lighted candles, should be placed on the apparatus.
6. Attention should be drawn to environmental aspects of battery disposal.
CURRENT IOOmA POWER 22W
I.TELESCOPIC ANTENNA
2.FUNCTION POWER SWITCH(BACK}
3.LED LIGHT ON/OFF SWITCH
4.STRAPS
5.LED LIGHT
6.BATTERY COMPARTMENT(BACK}
7.AC IN ( ONLY FOR CHARGE )
8.AUX IN JACK
9.REC/MP3 PLAY MONITOR(BACK}
10.USBSLOT
I I.SD CARD SLOT
12.RECffiELBUTTON
13.VOL+ BUTTON
14.VOL- BUTTON
IS.PLAY/PAUSE SCAN BUTTON(MP3/REC PLAY)
16.NEXT/CH+ BUTTON
17.PREV/CH - BUTTON
IS.DC 6V IN JACK(BACK}
A
I
I I
I
CAUTION
DO NOT OPEN
RISK OF ELECTRIC SHOCK
TO REDUCE
CAUTION
exclamation
The
THE RISK OF ELECTRIC
within
point
SHOCK. DO NOT REMOVE
triangle is a warning
COVER [OR BACK) NO USER
sign alerting you of
SERVICEABLE PARTS INSIDE.
important instructions
REFER SERVICING TO QUAL-
accompanying
IFIED SERVICE PERSONNEL.
product.
THE OPERATING MANUAL
- ---- -
SB method of use:
I .Push FUNCTION SWITCH to USB/SD position, insen U disk or SD CARD(U disk or SD
CARD must with AUDIO file) to corresponding socket, it will play AUDIO file automatically,
2.Pause play press ►I I, choose prev press I ◄◄ or the next song press ►►I
3.Press "VOL+" or "VOL-" button for speaker volume adjustment;
4.Press " ►II " button can convert play MP3 file or recorded file.
5.Press the "REC/DEL" button if you want to record, right now the recording indicator "REC"
light will be on, and then the tape on the source began recording the MIC position, to stop the
recording, press the "REC/DEL" button;
6.Press "REC/DEL" 3 seconds to delete the current playing file.
he radio to use:
I. Push the function
RADIO station, long press "SCAN" RADIO button started from 88-108 in the frequency of
the search can receive RADIO, after several minutes (depending on how many RADIO
stations and decide) search is done, can choose the RADIO, press "CH +" button will listen
to the next radio station, and press the "CH-" button is listening to prev radio station
2. Please insert USB/SD card to USB/SD slot if you want to record, then press "REC/DEL"
the
button,It can be radio recoding when the recording REC indicator lights, if you want to stop the
recording, press "REC/DEL" button;
the
oles:
l.This unit built-in rechargeable battery, and when the sound is not clear or voice becomes the
distortion, it means the unit Power is not enough, please charge in time (charging time every
time 8-10 hours);
2 .Charging method of use: will the AC plug "AC IN" socket, to the 110V or 220V can automatically
charged, when the unit is charge if you want to play MP3 maybe sound will have a little
distortion this is normal phenomenon, After the completion of the charge will be restored.
switch to "RADIO" position, about 3 seconds later can listen to the
