5. How to Wire Your Ceiling Fan
5.5
Securely connect the Fan White (neutral) Wire to the
Receiver White (FOR LIGHT) Wire using a 18 ga . Wire
Connector (supplied with receiver) (Figure 21) .
5.6
Securely connect the Fan Blue Wire to the Receiver
Blue (FOR LIGHT) Wire using a 18 ga . Wire Connector
(supplied with receiver) (Figure 22) .
5.7
Securely connect the Fan Grey Wire to the Receiver
Grey (TO MOTOR) Wire using a 18 ga . Wire Connector
(supplied with receiver) (Figure 23) .
FAN WHITE WIRE
Figure 21
RECEIVER WHITE WIRE
FAN BLUE WIRE
RECEIVER BLUE WIRE
Figure 22
FAN GREY
WIRE
RECEIVER
GREY WIRE
Figure 23
14
(Continued)
ETL Model No.: CF315
