AN-PH20EZ
OPERATION MANUAL
BEDIENUNGSANLEITUNG
MODE D'EMPLOI
MANUAL DE MANEJO
1
English
Deutsch
Français
Español
04.12.24, 14:28

Publicité

loading

Sommaire des Matières pour Sharp AN-PH20EZ

  • Page 1 English Deutsch AN-PH20EZ Français Español Wide-zoom lens for projector Weitwinkel-Zoomobjektiv für Projektor Objectif grand angle-zoom pour projecteur Objetivo granangular-zoom para proyector プロジェクター用短焦点ズームレンズ OPERATION MANUAL BEDIENUNGSANLEITUNG MODE D’EMPLOI MANUAL DE MANEJO AN_PH20EZ_Hyou01_04.p65 04.12.24, 14:28 Downloaded from: http://www.usersmanualguide.com/...
  • Page 2 Picture size and projection distance chart Side View Top View Screen Lens center Screen Lens center Leftmost lens shift Lower lens shift Center of position position screen (High mount setup) Lens center Upper lens shift Rightmost lens shift position position Lens center (Desktop setup) NORMAL Mode (4:3)
  • Page 3 • Lens cap (rear) – 1 • Installation manual • Operation manual (this manual) Specifications Product type Wide-zoom lens for projector Model AN-PH20EZ Type of lens Zoom lens Picture size (diagonal) 60'' to 250'' (4:3) Focal length 21.2 mm ( '') –...
  • Page 4 Tabelle für Bildformat und Projektionsentfernung Ansicht von der Seite Ansicht von oben Bildwand Objektivmitte Bildwand Objektivmitte Ganz linke Lens Untere Lens Bildwand- Shift-Position Shift-Position mitte (Erhöhte Einrichtung) Objektivmitte Obere Lens Ganz rechte Shift-Position Lens Shift-Position Objektivmitte (Benutzeroberflächen- einrichtung) NORMAL-Modus (4:3) Die Formel für die Bildgröße Entfernung von der Unterkante des Entfernung von...
  • Page 5 • Objektivkappe (Vorderseite) – 1 • Objektivkappe (Rückseite) – 1 • Installationsanleitung • Bedienungsanleitung (diese Anleitung) Technische Daten Produkttyp Weitwinkel-Zoomobjektiv für Projektor Modell AN-PH20EZ Objektiv-Typ Zoomobjektiv Bildformat (diagonal) 60'' bis 250'' (4:3) Brennweite 21,2 mm ( '') – 25,8 mm (1...
  • Page 6 Format de l’écran et distance de projection Vue de côte Vue de dessus Écran Centre de l'objectif Écran Centre de l'objectif Position de déplacement Position de déplacement Centre de tout à fait à gauche de l’objectif inférieur de l’objectif l'écran (Configuration de montage haute) Centre de l'objectif...
  • Page 7 • Manuel d’installation • Mode d’emploi (ce manuel) Caractéristiques Type de produit Objectif grand angle-zoom pour projecteur Modèle AN-PH20EZ Type d’objectif Objectif-zoom Taille de l’image (en diagonale) 60'' à 250'' (4:3) Longueur focale 21,2 mm ( '') – 25,8 mm (1 F no.
  • Page 8 Tamaño de la pantalla y distancia de proyección Vista superior Vista lateral Pantalla Centro del objetivo Pantalla Centro del objetivo Posición de orientación Posición inferior de del objetivo a la izquierda Centro de orientación del objetivo la pantalla (colocación elevada) Centro del objetivo Posición de orientación Posición superior de...
  • Page 9 • Manual de instalación • Manual de manejo (este manual) Especificaciones Tipo de producto Objetivo granangular-zoom para proyector Modelo AN-PH20EZ Tipo de objetivo Objetivo zoom Tamaño de la imagen (diagonal) 60'' a 250'' (4:3) Distancia focal 21,2 mm ( '') – 25,8 mm (1 Núm.
  • Page 10 圖像大小和投影距離圖表 側視圖 頂視圖 投影屏幕 鏡頭中心 投影屏幕 鏡頭中心 最左側鏡頭移動位置 底側鏡頭移動 屏幕中心 位置 高置式設置 鏡頭中心 上側鏡頭移動 最右側鏡頭移動位置 位置 桌面設置 鏡頭中心 正常模式 (4:3) 計算圖像尺寸和投影距離 鏡頭中心到圖像底部的距離 [H] 圖像 投影屏幕 尺寸 投影距離 [L] 鏡頭中心到圖像中 的公式 心的距離 [W] 對角線 [ 寬度 高度 最近 [L1] 最遠 [L2] 下側...
  • Page 11 調節圖像尺寸和聚焦 有關調節聚焦和圖像尺寸的信息﹐請參閱投影機使用說明書中的 圖像投影 部分。 操作注意事項 ● 請勿拆卸該鏡頭。 任何需要打開機殼的保養和檢查﹐請向授權的經銷商咨詢。 ● 接觸任何其他的內部部件會引起人身傷害或引起機器故障。 ● 請勿觸摸鏡頭玻璃或凸起部件。這會引起人身傷害並降低投影機的性能。 ● 保養投影機時﹐應注意下列幾點。 • 清潔鏡頭時﹐必須使用商店有售的氣吹或鏡頭清潔紙 用于清潔眼鏡和照相機 。 • 鏡頭表面非常精密。請勿用硬的物體撞擊或摩擦。 注意 ● 存放或搬運投影機時﹐請勿將鏡頭安裝到投影機上。否則可能對其造成損壞。 隨機附件 • 鏡頭蓋 內橡膠墊圈 – 1 • 鏡頭固定螺釘 – 3 • 鏡頭蓋 前部 – 1 • 鏡頭蓋 后部 – 1 •...
  • Page 12 22.0 ±35.2 H2= 0.20754 –62.3 20.8 ±33.2 –57.3 19.1 W= ± 0.33207 ±30.6 –52.3 17.4 ±27.9 –44.8 14.9 ±23.9 –37.4 12.5 ±19.9 メモ ∫ 上記の近似式には±3%の誤差があります。 ∫ 表中に− (マイナス記号) がついた値はレンズの中心の距離がスクリーンの下になることを示しています。 AN-PH20EZ̲J.PM6 Adobe PageMaker 6.0J/PPC Page 2 04.12.24, 14:29 Downloaded from: http://www.usersmanualguide.com/...
  • Page 13 ∫ レンズカバー (内側ラバーのリング)  1個 ∫ レンズ取付用ネジ 3本 ∫ レンズキャップ (前側)  1個 ∫ レンズキャップ (後側)  1個 ∫ 設置手順書 ∫ 取扱説明書 (本書) 仕様 品名 プロジェクター用短焦点ズームレンズ 形名 AN-PH20EZ レンズタイプ ズームレンズ 画面サイズ (対角) 60〜250型 (4:3) 焦点距離 21.2 〜 25.8mm F値 画面幅と投映距離の比率 1:1.5 〜 1.8 質量...
  • Page 14 Memo AN_PH20EZ_MEMO.p65 04.12.24, 14:39 Downloaded from: http://www.usersmanualguide.com/...
  • Page 15 SHARP CORPORATION Printed in China Gedrukt in China Imprimé en Chine Impreso en China 9NK5010019700 05P01-CH-NM AN_PH20EZ_Hyou01_04.p65 04.12.24, 14:28 Downloaded from: http://www.usersmanualguide.com/...
