4.5 Reset after a fault

RESET
MODE
°C
HEAT

5.0 Messages and faults.

5.1 Initial screen

°C

5.2 Software version

To call up details of the software version, press the Info button during normal operation.
This has no effect on the system's operation. After a few seconds, the main display appears again
automatically.

5.3 Display message OFF

The message "OFF1" appears in the display when the appliance is locked out. The digit, "1" in
this case, is the appliance number.
If multiple appliances are connected to the BaseTherm, a different digit may appear (1 to 8
inclusive).
MODE
°C
AUTO
°C
Press the reset push-button to reset the system after a fault.
"rES" appears in the display and flashes for a few seconds.
The appliances connected to the thermostat have been successfully reset
when the main screen appears again.
If a message is still visible on the screen after resetting has taken place,
please refer to chapter 6 for details of the message and the appropriate
solution. Please refer also to the technical documentation for the air
heater.
When the voltage supply to the appliances and thermostat is switched on,
"-- --" appears in the display for the first few seconds.
This indicates that initialisation is taking place. The main screen is
displayed as soon as initialisation has been completed.
Cause of the OFF message: The lock-out is caused by a break in the
external circuit or jumper across terminals 1 and 2 of the
appliance. After resolution of the problem, the message disappears and
the appliance will resume normal function.
To run through all the messages: You can scroll through all the messages by
pressing the blue info button and then pressing the up and down button.
