7.3.3 Control elements
The control elements shown on the display, which are used for performing settings in the inverter,
are described below using illustrative examples.
Selection list with check boxes
2 2
2 2
2 2
Selection list with radio buttons
2 2
2 2
2 2
Dialogs (general)
Numerical settings
2 2
742.641 | 11.43
 Designation of the selection list
1
 Check boxes with names:
3
 Scroll bar
 Designation of the selection list
1
 Radio buttons with names:
3
 Scroll bar
 Dialog heading
1
 A question presented to the user
 Response possibilities:
2 2
Confirm (answer the question with Yes): press and hold
3
 Designation of the numerical setting
1
 Value to be set; the selected value to be set is highlighted
2 2 2 2
When performing numerical settings of remuneration and
dates, the following applies:
Remuneration
• Possible currencies: £ (pound), € (euro), kr (krone), none
• The maximum value that can be set for remuneration is
Date
When setting the month/year, a check is performed to ensure
that the selected day is valid. If not, then the day is automati-
cally corrected.
Example: 31.02.2011 is corrected to 28.02.2011.
Check boxes allow multiple selection
–
The currently selected check box is highlighted in black
–
Preset check boxes have no frame and are always
–
switched on (cannot be changed)
Radio buttons are exclusive-OR (only one radio button
–
can be switched on)
The currently selected radio button is highlighted in
–
black
Back (cancel): press ESC
SET for 1 second
in black
limited for technical reasons. If necessary, the remunera-
tion must be set using different units. Example: dollars
instead of cents (set a currency of none).
