GPS receiver
Antenna connector type: FAKRA
NAV ready: Navigation possible with separately available navigation kit MAC 500 NAV-SET
Monitor
Screen Size: 17 cm / 6.8" (Measured diagonally), 16:9 Widescreen
Screen Type: TFT Liquid Crystal Display (LCD) active matrix
Resolution: 1,152,000 pixels, 800W (x3) X 480H WVGA
General
5 Line audio outputs: 2x front, 2x rear and subwoofer (4 V RMS / 200 ohms)
10-band equalizer
Power Output: max. 4 x 50 Watt (total: 200 Watt)
Power Supply: 11 to 16VDC, negative ground
Power Antenna (Blue): 500mA max, current limited protection
Operating Temperature: 0°C ~ 60°C
Fuse: 15 Ampere, Mini ATO
DIN chassis dimensions: 178 x 100 x 162 mm
Weight: 2,0 kg (incl. all cable adapters and DAB+ antenna)
*Specifications subject to change without notice.

CARE AND MAINTENANCE

1. Use only a clean silicone cloth and neutral detergent to clean the front panel or monitor.
A rough cloth and non-neutral detergent (such as alcohol) may result in scratching or
discoloration.
2. Do not get water or cleaning fluids on the unit.
3. If the temperature inside the player gets too hot, a protective circuit
automatically stops play of the disc. If this occurs, allow the unit to cool before operating the
player again.
4. Never insert anything other than a 12 cm (5") compact disc into the player as the mechanism
can be damaged by foreign objects.
5. Do not attempt to use a 8 cm (3") CD-Single disc in this unit, either with or
without an adaptor, as damage to the player and/or disc may occur. Such
damage is not covered by the Warranty on this product.
6. The CD player may not operate properly in extreme hot or cold. If such conditions occur, allow
the interior of the vehicle to reach a normal temperature before
using player.
7. When the vehicle warms up during cold weather or under damp conditions,
condensation may appear on the LCD panel. Should this occur, the screen will
not operate properly until the moisture has evaporated.
8. We suggest you use a cleaning disc in this unit more frequently than in the unit in your home
due to the environmental conditions of the vehicle.
