ESC features.
1. Fully proportional forward with on/off brake and reverse
2. Smooth throttle response
3. Selectable Motor type (Sensorless BLDC, Sensored BLDC, Brushed DC)
4. Li-Po, Li-Fe, NiMH(NiCd) battery compatible
5. Various Brake System(Speed Mixing Brake, ABS Brake, Auto / Minimum / Maximum Brake)
6. Selectable One Way / Two Way
7. Easy setting and providing traveling information when using the program card.
8. Brushed (2 kHz) Sensored(2 kHz switching frequency), Sensorless(32KHz)
9. Thermal protection Function
*** when sensorless mode is used, sensorless motor or motor without
sensor wires must be used.
ESC Stick Position setup
1. Turn on the transmitter.
2. Connect the power battery, and switch on the ESC.
3. If all connections are correctly completed, the motor should beep depending on the throttle stick
location.
Do, Re ~~ Do, Re, Mi
Do, Re ~~
4. If you press and hold the setup button for over 1second, the Green LED should flash. At this time,
detach your hand from the button, then the Green LED should be ON and the motor should beep (So, So,
La, La, So, So sound ) to indicate that the neutral position has been set.
5. Move the throttle stick to the full power position, then the red LED should be ON to indicate that the
full power position has been set.
6. Move back the throttle stick to the full reverse or full brake position, then the red and Green LEDs
should be ON to indicate that the full reverse or full brake position has been set.
7. Move the throttle stick to the neutral position, then the red and Green LEDs should flash alternatively,
and the motor should beep (So, Fa, Mi, Re, Do sound ), then the Green LED should be ON to indicate
that the ESC is now ready to be used.
Note 1: It is ONLY necessary to make this initial throttle setup again if you are using a different
transmitter or the settings have been changed.
Note 2: After switching on the ESC, the stick position setup COULD be done ONLY before a motor turns.
Note 3: If full power position setting can not be done, pls change the Throttle reverse / Normal.
ESC sound : Do, Re, Mi, Fa, So, La, Ti Do.
: If the stick is at the neutral position,
: If the stick is at other position instead of neutral position.
