been carried out by the after-sales
service or by an authorized expert.
This concerns the accessories, too.
Assembling
instructions
GFig. A*: Fit the telescopic spray
tube to the trigger control valve.
G Fig. B: Screw the hose into the
quick-action valve.
G Fig. C: Fix the free end of the hose
onto the conical take-up of the hose
connection at the base of the tank,
put the hose connection nut over the
hose connection up to the first thread
and tighten it manually.
G Fig. D: Fix the spray tube by bend-
ing the nozzle and inserting it into the
spray tube fixing device in the base.
Clip** or hang** the spray tube into
the filling funnel.
*spray tubes vary according to type of
extinguisher.
**fixing devices vary according to type
of extinguisher.
Assembly of carrying strap
G Fig. E: Carrying strap to be fixed
onto suspension hooks of the tank
with the inside punchings. In order to
secure the hold, the excess end is to
be bended and fixed with the outside
punchings.
G Fig. F (hobby exclusiv 262):
Put in the shoulder pad and fix the
carrying strap as described at the op-
posite side of the tank.
Assembly of the spray shield
(hobby exclusiv 262)
G Fig. G: Separate both inserts from
spray shield.
Note
Insert 1: for model hobby
exclusiv 262
Insert 2: for other Gloria models
G Fig. H: Snap insert 1 into the spray
shield. Fix spray shield onto
nozzle.
Telescopic spray tube
(hobby exclusiv 262)
G Fig. I: Telescopic spray tube can be
adjusted in length according to the
working situation. Unscrew slightly,
adjust spray tube to the length re-
quired and fix it again.
