IMG STAGELINE LSE-4LRG Mode D'emploi page 15

DMX value Function
Channel 5: white strobe LEDs
000 – 009 blackout (strobe LEDs off)
running light pattern 1, fast ➞ slow
010 – 019
running light pattern 2, fast ➞ slow
020 – 029
running light pattern 3, fast ➞ slow
030 – 039
running light pattern 4, fast ➞ slow
040 – 049
running light pattern 5, fast ➞ slow
050 – 059
running light pattern 6, fast ➞ slow
060 – 069
running light pattern 7, fast ➞ slow
070 – 079
running light pattern 8, fast ➞ slow
080 – 089
running light pattern 9, fast ➞ slow
090 – 099
running light pattern 10, fast ➞ slow
100 – 109
110 – 255 strobe LEDs constantly switched on
Channel 6: lasers
000 – 009 blackout (lasers off)
010 – 049 red laser switched on
050 – 089 green laser switched on
090 – 129 change red / green
130 – 169 red on; green on /off
170 – 209 green on; red on /off
210 – 255 red and green on/off
Channel 7: switching speed for the lasers
000 – 004 no switching
fast (30 Hz) ➞ slow
005 – 254
255 music control
Channel 8: rotation of the colour LED beams
000 – 004 no rotation
slow ➞ fast
005 – 127
128 – 133 no rotation
slow ➞ fast (opposite direction)
134 – 255
Channel 9: rotation of the laser beams
000 – 004 no rotation
slow ➞ fast
005 – 127
128 – 133 no rotation
slow ➞ fast (opposite direction)
134 – 255
All rights reserved by MONACOR
be reproduced in any form or by any means for any commercial use.
Set the speed
via channel 7.
INTERNATIONAL GmbH & Co. KG. No part of this instruction manual may
®
6 Specifications
Laser
Laser class: . . . . . . . . . . 3 R; for a distance
Power / wavelength
red laser: . . . . . . . . . . 100 mW/ 650 nm
green laser: . . . . . . . . 50 mW/ 532 nm
Laser beam angle: . . . . 140°
LEDs
strobe LEDs: . . . . . . . . . 8 LEDs (white),
colour LEDs: . . . . . . . . . 5 LEDs (red, green,
Data protocol: . . . . . . . . . . DMX 512
Number of DMX channels: 9
Power supply: . . . . . . . . . . 230 V~ / 50 Hz
Power consumption: . . . . . 35 VA max.
Ambient temperature: . . . 0 – 40 °C
Dimensions: . . . . . . . . . . . 260 × 250 × 220 mm
Weight: . . . . . . . . . . . . . . . 4.2 kg
Note: Due to the high output power, the laser diodes are
subject to extreme stress and therefore only have a limited
lifetime. As with all wearing parts, no warranty claims for the
laser diodes can be accepted.
Subject to technical modification.
exceeding 1 m, laser
class 2 M applies
1 W for each LED
blue, white, amber),
3 W for each LED
