To ensure this product is correctly installed and used appropriately, we highly advise you
to read this user guide very carefully.
1 . I N T R O D U C T I O N
Z3 Zenergy Box UPS range has been designed to provide an optimum
protection to PC and multimedia equipments.
With 6 or 8 outlets depending on the model, Z3 Zenergy Box UPS allows to plug
and protect all your equipments simultaneously from power disturbances. Half of
these outlets are backup time outlets and they make the connected equipments
working up to 18 minutes during mains power cut. I n addition, it protects your
I nternet/ xDSL modem with its RJ45 line protection.
2 . M A I N C H A R A C T E R I S T I C S
 A highly-reliable microprocessor control
 High frequency technology
 Automatic restart during AC power recovery
 Cold start feature if no power supply
 Automatic frequency detection
 Indicator lights and an audible alarm
 Compact size and lightweight

Phone/modem or network surge protection
3 . S A F E T Y I N S T R U C T I O N S – S e c u r i t y
 Risk of electric shock:

The UPS unit uses potentially hazardous voltages. Do not attempt to disassemble
this equipment as it does not contain accessible components that can be repaired by
users, fuse change excepted.

All repairs should be performed by qualified technicians only.

The utility power outlet shall be near the equipment and easily accessible. To
isolate the UPS from AC input, remove the plug from the utility power outlet.

The UPS has its own internal power supply (battery). There is a risk that output
sockets may still be live after the UPS has been disconnected from the mains power
supply.

In an emergency situation, switch the UPS to the "Off" position and disconnect the
unit from the AC power supply.

When the UPS is out of order, please refer to section: "trouble shooting" and call
the hot line.
 Connected products:

Combined UPS and connected equipment leakage current should not exceed 3,5
mA.

Make sure that the connected load does not exceed UPS capabilities. To ensure
improved backup time and longer battery life, we recommend a load equivalent to 1/3
of nominal power.

Do not plug the UPS input into its own output socket.

Do not plug the UPS into a power strip or surge suppressor.
