Controllers
7
Directional buttons
8
SELECT button:
to select 1 or 2 players
(if available in the game)
Main unit:
Note: Make sure the TV and the main unit are
off before connecting.
1. Connect the micro USB cable to the micro
USB port of the main unit.
4
2. Plug the other end of the micro USB
cable into the USB port on your TV. If your
TV doesn't have a USB port, you can plug
the cable on a wall socket using a power
adapter with USB port (not included).
3. Connect the main unit to your TV:
• Plug the yellow end of the AV cable into the video jack
the corresponding input in the TV.
• Plug the red and white ends of the AV cable into the audio jacks
other ends to their corresponding input in the TV.
4. Turn the TV on and press the POWER button
In order to show the image transmitted by the main unit, you must set your television to the input
Note:
jack being used. Input selection button may be located differently upon TV manufacturer and labeled
as: select, input, input select, line, line in, source, in, EXT or AUX.Please refer to your TV's instruction
manual for further information.
For the best playing experience, it is recommended to use the "4:3" or "Original" display setting of
Note:
your TV set (if available). Using other display settings may result in distorted images.
JG7800DC-1_JG7800FZ-1_JG7800PJM-1_IM1218_V09_317.indb 8
Plug N' Play
TV Game Console
10
9
MENU button: to go back to the game list
installation
5
of the main unit.
2
8
12
B and A TURBO buttons:
have the effect of pressing the
B and A buttons really quickly if
you just hold them down. Very
useful for some games!
11
START button
of the main unit. Connect the other end to
of the main unit. Connect the
6
B and A buttons
