Introduction
Thank you for buying this SpringCard FunkyGate
Reader for your access control system. SpringCard
FunkyGate is a wall-mount reader. In order to install
it easily and correctly please follow the instructions
contained in this guide.
Product listing
This Installation Instruction guide targets the
following products :
Order # Product
SC16092 FunkyGate-IP PC/SC: new generation
wall-mount RFID/NFC/contactless card
Reader, with Ethernet interface (10 or
100 Mbit/s)
Precautions for installation & use
The SpringCard FunkyGate IP PC/SC Coupler
communicates with contactless cards, tags or any
other objects by the mean of RFID/NFC technology in
13.56MHz range. RFID/NFC works thanks to short
distance radio waves that propagates on a straight-
line (magnetic field).
These radio waves can't travel through metal. The
coupler's operations may also be disturbed because
of other active devices in the nearby. Please respect
the following rules when installing your SpringCard
FunkyGate IP PC/SC Coupler.
The antenna shall not be installed in the

vicinity of any other RFID or NFC reader,
even from another manufacturer or
technology. The distance between two
readers shall be at least 30cm,
Contacting Support
Thank you for using the online form at address
support request.

INSTALLATION INSTRUCTIONS

Do not install your SpringCard FunkyGate Reader:

even from another brand or another technology. The
distance between two readers in the 13.56MHz range
shall be 30cm or more ;

(aluminium door or window frame, thermal
insulation screen etc). There must be at least 8cm
between the Reader's back and any metal plate, and
there must be at least 12cm between the Reader's
sides and any object containing metal in the nearby ;

waves it emits for operation, or even its internal
shielding, may alter the performances of your
SpringCard FunkyGate Reader.
Wiring, configuration and test
Once your SpringCard FunkyGate Reader is installed,
the next step is to connect it to your access control
system, and to load the correct configuration
depending on:


for.
The rest of the document is a configuration tutorial
for the first use of your reader.
www.springcard.com/support
PMU18296-AA
It is highly disadvised to place any metallic

or conductive area in front of the antenna
because it could distort the operation of
your antenna,
Keep away from any electronic equipment

that is likely to disturb the communication
at 13.56MHz,
In the vicinity of another access control reader,
On a metal plate, or near any kind of metal area
Near another electronic equipment, because the
The kind of cards/tags you'll be using ;
The output format your controllers are waiting
for any question or technical
5/12
