Endress+Hauser Micropilot FMR62 Information Technique page 32

32
1)
Antenne
Angle d'émission α
Distance (D)
5 m (16 ft)
10 m (33 ft)
15 m (49 ft)
20 m (66 ft)
25 m (82 ft)
30 m (98 ft)
35 m (115 ft)
40 m (131 ft)
45 m (148 ft)
50 m (164 ft)
60 m (197 ft)
70 m (230 ft)
80 m (262 ft)
1) Caractéristique 070 dans la structure du produit
FMR62
Intégrée, Intégrée,
PEEK, 20 PEEK, 40 mm / 1-1/2"
mm / 3/4"
14 ° 8 °
Diamètre du faisceau W
1,32 m 0,70 m (2,29 ft)
(4,33 ft)
2,63 m 1,40 m (4,58 ft)
(8,63 ft)
- 2,09 m (6,87 ft)
- 2,79 m (9,16 ft)
- -
- -
- -
- -
- -
- -
- -
- -
- -
Micropilot FMR62
A0032081
Plaquée PTFE Plaquée PTFE
affleurante affleurante 80 mm / 3"
50 mm / 2"
7 °
0,61 m 0,26 m (0,85 ft)
(2,00 ft)
1,22 m 0,52 m (1,71 ft)
(4,00 ft)
1,83 m 0,79 m (2,59 ft)
(6,01 ft)
2,44 m 1,05 m (3,44 ft)
(8,01 ft)
3,05 m 1,31 m (4,30 ft)
(10,02 ft)
3,66 m 1,57 m (5,15 ft)
(12,02 ft)
4,27 m 1,83 m (6,00 ft)
(14,02 ft)
4,88 m 2,09 m (6,86 ft)
(16,03 ft)
5,50 m 2,36 m (7,74 ft)
(18,03 ft)
6,11 m 2,62 m (8,60 ft)
(20,03 ft)
- 3,14 m (10,30 ft)
- 3,67 m (12,04 ft)
- 4,19 m (13,75 ft)
Endress+Hauser
A0032082
3 °
