- EN -

Installation and connection

W A R N I N G
Possible death or severe injury from hazardous electrical voltage!
• Prior to reaching into the water, isolate (switch off and disconnect) all units/devices used in the water.
• Isolate the device (disconnect from the power supply) before carrying out any work on it.
W A R N I N G
Death or serious injuries from hazardous electrical voltage due to operation of this unit in a swimming pond.
• Never operate this unit in a swimming pond.
N O T E
If the pump is used for conveying excessively soiled water, the impeller unit will be subject to increased wear
and will require earlier replacement.
Remedy:
• Thoroughly clean the pond or pool before installing the pump.
• Install the pump approx. 200 mm above the floor of the pond to avoid excessively soiled water from being
drawn into the pump.
The unit is either submerged or set up in a dry location.
The use of the pump is only permitted with observance of the specified water quality. (→ Water quality)
• Pool water or salt water can impair the appearance of the unit. Such impairments are excluded from the guarantee.
Submerged installation of the pump
Adhere to the following conditions for dry installation:
 C
• Never operate the pump in a swimming pond.
• Only operate the pump when it is below the water surface level.
• Only operate the pump with the filter basket fitted.
• Ensure that the pump is in a secure and stable position.
• The position of the pump outlet can be changed. The pump casing has to be turned to achieve a different position.
(→ Turning the pump casing to achieve a different position )
Connecting the hose
• AquaMax Eco Expert 21000/26000: On the outlet, use the 50 mm (2") hose connector or the 38 mm (1½") hose con-
nector.
• AquaMax Eco Expert 36000/44000: On the outlet only use the 50 mm (2") hose connector, if at all possible.
How to proceed:
 D
1. Screw the stepped hose adapter including union nut and sealing ring to the outlet.
2. Slip the hose clip over the hose, fit the hose onto the hose connector and secure with the hose clip.
18
