RugGear R6160 Guide Rapide page 4

4. Mouse cursor Press it briefly to move the mouse
pointer.
5. Answer key Use it to place a call and answer the
phone.
6. Star key To activate and deactiviate the key lock.
7. Micro USB For charging and to connect to
external USB devices.
8. Earphone jack To connect an earphone with
3,5 mm jack.
9. # key Long press to set the device to silent mode.
10. Navigation key Use it to move the cursor around
the screen.
11. OK To confirm the chosen window.
12. On/Off power key Long press to power ON/OFF
the device. To terminate a call and direct return to
the home screen.
13. Delete key Use to move characters entered in
a field.
14. Back key Use it to return to the submenue.
3. Installation of SIM/microSD card
The device is designed to fit two standard SIM cards
and one microSD card.
3.1. Unfasten the screws on the battery cover and lift
it carefully to open the compartment.
3.2. Insert the microSD card and the SIM cards into
the corresponding slots. The device supports up
to 32Gb with a memory card.
4. Installing an uninstalling the battery
4.1. Turn off the phone.
4
