10 - Installation

10.1 Unpacking
WARNING!
▶ The appliance is heavy. Always handle with at least two persons.
▶ Keep all packaging materials out of childrens reach and dispose them in an environ-
mentally friendly manner.
▶
Take the appliance out of the packaging.
▶
Remove all packaging materials.

10.2 Environmental conditions

The room temperature should always be between 10 °C and 43 °C, since it can influence
the temperature inside the appliance and its energy consumption. Do not install the appli-
ance near other heat-emitting appliances (ovens, refrigerators) without isolation.
10.3
W1
D1
W2
10.4
10 cm
10 cm
10 cm
10.5
max 45°
1.
3.
20

10.3 Space requirements

D4
Required space to open the door (Fig. 10.3):
D2 D3
Width
in mm
W1
595 955
10.4 Ventilaton cross-section
10 cm
To achieve sufficient ventilation of the appliance for
safety reasons, the information of the required ventila-
tion cross sections must be observed (Fig. 10.4).

10.5 Aligning the appliance

The appliance should be placed on a flat and solid sur-
face. If the appliance is placed on a pedestal, strong and
fire-resistant materials must be used. Never use the
foam packing material as a pedestal.
1. Tilt the appliance slightly backwards (Fig. 10.5).
2. Set the feet to the desired level.
2.
3. The stability can be checked by alternately bump-
ing on the diagonals. The slight swaying should be
the same in both directions. Otherwise the frame
can warp; possible leaking door seals are the result.
A low tendency to the rear eases the closing of the
door.
Depth
in mm
W2 D1 D2
592 1105
Distance to wall
in mm
D3 D4
1215 100
