Panel Mounting - Faster Multifaster P1 Serie Livret D'instructions

PS... series MULTIFASTER can be assembled
PD... and PW... series MULTIFASTER have been designed to
be directly integrated on the valve.
Follow the specific instructions given with the product.
Versions PS...
both on the valve and on a panel.
Versions PD... PW...
Mounting on
the valve
Apply
directly on the valve by using
the proper FASTER fittings
AD12G-DMLR1,5 series as
shown in the drawing.
Fittings are not included with
MULTIFASTER.
the
Panel
mounting
Arrange on the fixing panel
two holes diameter 8,5 as
shown in the picture.
MULTIFASTER
the
by using M8 hexagonal head
cap screws.
Screws are not included with
MULTIFASTER.
the
23
MULTIFASTER
the
Apply
fixed part
