Dear Customer,
Congratulations on purchas-
ing your new STEINEL sensor
and thank you for the confi-
dence you have shown in us.
You have chosen a high-
quality product that has been
manufactured, tested and
packed with the greatest care.

Safety Precautions

í
Disconnect the power sup-
ply before attempting any
work on the sensor!
í
During installation, the
electric power cable to be
connected must be dead.
Therefore, switch 'OFF' the
power first and use a volt-
Installation/Wiring
The sensor is only intended
for concealed, indoor instal-
lation in ceilings (apart from
the COM 1 AP - surface-
mounted - option). A clamp-
ing-type ceiling adapter or
surface-mounting adapter is
not included. Sensor and
load module come ready as-
sembled and must be
plugged together after fitting
the load module and setting
the potentiometers/dip

System Components

Load module
Catch mechanism
LED traffic light logic
Sensor module
Please familiarise yourself with
these instructions before at-
tempting to install the product
because prolonged, reliable
and trouble-free operation will
only be ensured if it is fitted
and used properly.
age tester to make sure
the wiring is off circuit.
í
Installing the sensor in-
volves work on the mains
power supply. This work
must therefore be carried
out professionally in
accordance with the
switches. The sensor module
must now be locked in place
with the catch mechanism
, using a screwdriver if
necessary.
Installation site: Do not fit
the unit inside shelf units or
behind curtains and similar
covers so that the room's
normal convection air can
reach the air-quality sensor
without obstruction.
k
5. Kaiser stud-wall junction
1
box, optional
k
5. Clamping-type ceiling
2
adapter, optional
Surface mounting adapter
- 9 -
We hope your new STEINEL
sensor will bring you lasting
pleasure.
applicable national wiring
regulations and electrical
operating conditions (VDE
0100).
Draughts from windows and
doors as well as external
walls must be avoided.
Accessories:
Kaiser junction box for stud
walls
EAN No.: 4007841 000370
Clamping-type ceiling adapter
EAN No. 4007841 002855
Surface mounting adapter,
EAN No.: 4007841 000363
Dip switches
(1) Acoustic warning signal
'ON' / 'OFF'
(2) LED 'ON' / 'OFF'
Sensor base
Installation / wiring
