Instructions for installation
Name
No. of
items
Support slats
1 Roof support slat
1 Roof support slat
2 Roof support slat 1 x 45°
1 Roof support slats 2 x 45°
1 Roof support slat
1 Roof support slat
2 Roof support slat 1 x 22.5°
1 Roof support slat 1 x 22.5°
1 Bench support slat 1 x 45°
1 Bench support slat
3 Bench support slats
2 Mounting slats for bench screen
Interior fittings
1 Bench
1 Bench with adjustable backrest
1 Bench
1 Bench cover slat
2 Backrests
2 Backrests
1 Bench screen
1 Heater safety guard, 3 parts
1 item 57 x 75 cm, 2 items 45.5 x 55 cm
1 Floor grid
2 Headrests
1 Lamp protection grille
1 Ventilation slit
p. 7/38
Dimensions
197 x 4 x 4 cm
193 x 4 x 4 cm
141.6 x 4 x 4 cm
89.7 x 4 x 4 cm
196 x 1.2 x 4 cm
192 x 1.2 x 4 cm
141.2 x 1.2 x 4 cm
83.2 x 1.2 x 4 cm
142.3 x 4 x 4 cm
120 x 4 x 4 cm
58 x 4 x 4 cm
26 x 4 x 4 cm
195 x 62 x 9 cm
195 x 62 x 9 cm
133.5 x 62 x 9 cm
72.3 x 14 x 2 cm
101 x 26 x 5 cm
53 x 26 x 5 cm
195 x 35 x 5 cm
57 x 475 x 75 cm
70 x 53 x 4 cm
43 x 25 x 7 cm
38 x 32 x 4 cm
52 x 14 x 1.5 cm
