Connecting the SFP+ Ports
First install SFP+ transceivers and then connect the fiber optic cable to the transceiver ports, or directly
connect DAC cables to the SFP+ slots.
CAUTION:
Laser beams will cause eye damage. Do not look into bores of optical modules
or optical fibers without eye protection.
Connecting the QSFP28 Ports
First install QSFP28 transceivers and then connect the fiber optic cable to the transceiver ports, or
connect DAC cables to the QSFP28 slots.
