Intended Use

The YD.01C-... data output port
(YDO01C-232: Option A1,
YDO01C-485: Option A2/A3,
YDA01C-20MA: Option A4,
YDO01C-DP: Option B1, YDO01C-EN:
Option B9) is designed for installation
in Combics indicators and complete
scales, models CISL., CIS., CW.P and
CW.S as an optional UniCOM universal
data interface.
The YD.01C-... data output port can be
configured for use as one of the follow-
ing types of interface:
– YDO01C-232 (Option A1):
Bi-directional RS-232 data interface.
The YDO01C-232 module enables con-
nection of any of a number of printers
(YDP01IS, YDP02, YDP03, YDP02IS,
YDP04IS or a universal printer driver) or
a second weighing platform or digital
compact scale (WP2) 1 ) for use in either
SBI or xBPI mode, data exchange with
a PC (in SBI, xBPI or SMA mode), or for
connection of an alibi memory.
– YDO01C-485 (Options A2 and A3):
Bi-directional data interface, electri-
cally isolated, for use with the RS-422
(Option A2) or RS-485 (Option A3)
protocol.
The YDO01C-485 module enables
connection of a second weighing plat-
form or digital compact scale (WP2)
(IS weighing platform or YCO02IS) or
data exchange with a PC (in xBPI or SBI
mode).
– YDA01C-20MA (Option A4):
Analog output port for use as a cur-
rent interface (0/4 to 20 mA) or voltage
interface (0 to 5 volts).
The YDA01C-20MA module enables
connection of a PLC system or a remote
analog display unit.
– YDO01C-DP (Option B1):
Profibus DP interface (slave) for field
bus applications (e.g. enables connec-
tion to a PLC system).
2
– YDO01C-EN (Option B9) ):
Ethernet interface for field bus applica-
tions (e.g., for connection to a PLC).
1
)
Connection of a second weighing instrument
or platform not possible on Combics 1 models
2 )
Operation and configuration only with Combics
indicators without 25-pin interfaces.
Symbols
The following symbols are used in
these instructions:
§ Indicates required steps
$ Indicates steps required only under
certain conditions
> Describes what happens after you have
performed a certain step
Indicates a hazard
!
1
)
Intended Use
Contents
3 Intended Use
4 Configuring the Interface Module
4 YDO01C-232
4 YDO01C-485
5 YDA01C-20mA
7 YDO01C-DP
7 YDO01E-EN (B9)
Installation in the Indicator
8
11 Pin Assignment Charts
Configuring the UniCOM Interface
14
18 Display: Initialization Completed
18 Ethernet Interface: Features
19 Analog Interface Extension
YDA01C-20mA
YDO01C
3
