7. Wait for at least five minutes.
8. Re-connect the LP tank to the regulator valve.
9. With the lid open, turn the regulator valve to the high position and light the grill.
10. Observe stainless steel plate when lit: It should feel warm after five to ten seconds and the color of the stainless steel
plate should turn red in two to three minutes.
11. If the grill does not light, turn the regulator valve to the "LOCK OFF" position and disconnect the LP tank. Then
contact the customer service center for further assistance.

Care and Maintenance

IMPORTANT

Always allow to completely cool off before covering your grill to prevent corrosion from condensation.
Caution: All cleaning and maintenance should be done when the grill is cool, with the fuel supply turned off at the
control dial and the propane cylinder disconnected. DO NOT clean any grill part in a self-cleaning oven. The extreme
heat will damage the finish.
Cleaning the Burner Assembly
Burning off the grill after every use (approx. 15 minutes) will keep excessive food residue from building up.
Recommended cleaning materials -
Mild dishwashing liquid detergent
Nylon cleaning pad
Paper clip
Compressed air
DO NOT use cleaners that contain acid, mineral spirits or xylene.
Outside surfaces
Use a mild dishwashing detergent and hot water solution to clean. Rinse thoroughly with water.
Inside surfaces
If the inside surface of the grill lid has the appearance of peeling paint, baked-on grease has turned to carbon and is
flaking off. Clean thoroughly with a strong solution of detergent and hot water. Rinse with water and allow it to
completely dry.
Interior of grill bottom – Remove residue using brush, scraper and/or cleaning pad. Wash with a dishwashing
detergent and hot water solution. Rinse with water and let dry.
Cooking Grids –Use a mild dishwashing detergent or baking soda and hot water solution. Non-abrasive scouring
powder can be used on stubborn stains. Rinse with water.
Heat Plates – Clean residue with wire brush and wash with soapy water. Rinse with water.
Problem
Burner will not light using a match.
Irregular heat pattern.
GPT1813G
Instruction Manual
Guide d'utilisation
All manuals and user guides at all-guides.com
Hot water
Heat Resistant Acrylic brush
Putty knife/scraper

Troubleshooting

Possible Cause
No gas flow.
Obstruction of gas flow.
Disengagement of burner to valve.
Spider webs or insect nests in venturi.
Burner ports clogged or blocked.
Burner ports are clogged or blocked.
12
Prevention/Cure
Check if propane tank is empty. If empty, replace.
If propane tank is not empty, refer to "Excess
flow safety valve reset procedure" on page 11.
.
Clear burner tube.
Reengage burner and valve.
Clean venturi.
Clean burner ports.
Clean burner ports.
