SFX-HO150W - 150W Horiziode projector with white LED
4 - Internal menu
4.1 - Initialisation
Upon initialisation, the display will indicate:
Initialisation...
The projector initialises the functions of the internal program.
It will then enter standby mode and indicate:
CPU
Standby
LED
The projector is now ready to be used.
4.2 - Menu tree
Menu
DMX Functions
Lamp Setting
Lamp Behaviour
Display Setting
XX°C
XX°C
Sub-menu
DMX Address
DMX Channel Mode
View DMX Value
MOde 1
MOde 2
MOde 3
MOde 4
Halogen
LED
Display Inverse
Backlight Auto Off
Contrast Ratio
Temperature Unit
Allows you to set the DMX address. Values from 001 to 512.
Alloqs you to select the number of DMX channels used
DMX modes:
Mode 01 (1ch) : Dimmer
Mode 04 (2ch) : Dimmer/Strobe
Allows you to visualise the DMX value of the current function
Brightness settings are proportional to values indicated by the display
Brightness settings are exponential
Brightness settings are inversely exponential
Brightness increases slowly in lower values and strongly in higher values
Allows you to adjust dimmer speed:
Halogen : Progressive dimmer
LED : Instant dimmer
Rotates the display by 180°
Turns off the backlight when the menu buttons have not been used for 3 seconds
Increases or decreases contrast
Adjustable from 1 to 30
Allows you to select the measure unit used to display the temperature.
Celsius or Fahreinheit degrees
Action
English
