intakes to assure adequate combustion.
• The extractor outlet must not be connected to a
duct used to exhaust smoke or fumes from any
appliance that uses gas or any other type of fuel.
• This appliance is not intended for use by
young children or infi rm persons unless they
have been adequately supervised by a res-
ponsible person to ensure that they can use
theappliance safely. Young children should
be supervised to ensure that they do not play
with the appliance.
INSTALLATION
IMPORTANT: Before installing and wiring the EBB, ensure that the main supply
is disconnected.
Suitable for both ceiling and wall installation, the EBB fans may be adapted to an
individual duct or to a communal ventilation system (Fig. 1).
The discharge port, situated at the side on the back of the extractor housing,
enables it to be installed anywhere on the wall or ceiling, even in inaccessible
corners (Fig.2).
NOTE: Pullcord models M and HM should be mounted as shown in Fig.2.1 If NOT
mounted as Fig.2.1, a support (not supplied) must guide the pullcord so that it
does not rub the fan body. The pullcord (if used) MUST be easy tooperate.
Making use of the template enclosed, make a 100 mm diameter round hole in
the wall or ceiling.
NOTE: A 115 mm dia. hole is required if a wall sleeve isutilized.
Drill the holes for the screws and insert the respective plugs in them. Take the ex-
tractor fan and withdraw the grille by pressing on the shoulders at the bottom (Fig.3).
