4.2. Using an AC adapter (special accessory)
It is possible to operate this blood pressure instrument, with an AC adapter which complies with local
regulations (output 6 V DC / 600 mA with DIN plug).
a) Plug the plug into the socket at the left side of the
instrument.
b) Plug the mains adapter into a 230/110 V power socket.
c) Test that power is available by pressing the
Note:
• No power is taken from batteries while the AC adapter is connected to the instrument.
• If power is interrupted during the measurement (e.g. by accidental removal of AC adapter from the
socket), the instrument must be reset by removing the plug from its socket and re-inserting the
connections.
• Please consult your dealer if you have questions relating to the AC.

4.3. Cuff connection

Insert the cuff tube into the opening provided on the back
side of the instrument, as shown in the diagram.

4.4. Setting time and date

This blood-pressure monitor incorporates an integrated clock with date display. This has the advantage,
that at each measurement procedure, not only the blood-pressure values are stored, but also the exact
moment of the measurement.
After new batteries have been inserted, the device will request a user to set up time/date.
(Example: Entering 2008-08-15 Time 09:30)
1. After new batteries have been inserted, the display comes into
direct year setting, during which the 4 characters (2005) blink.
2. Enter the correct year by pressing «Memory» button. Each click
will change the clock one year. Example: 3 x press.
3. Press «Time» button. The display now switches to the current date,
during which the first character (month) blinks.
4. Enter the current month by pressing the «Memory» button.
Example: 7 x presses
20
button.
2005
2008
8
