CAUTIONS AND WARNINGS (CONTINUED)
 This equipment has been tested and found to comply with the EMC limits for the Medical
Device Directive 93/42/EEC (EN 55011 Class A and EN 60601-1-2). These limits are
designed to provide reasonable protection against harmful interference in a typical medical
installation. The equipment generates, uses and may radiate radio frequency energy and, if
not installed and used in accordance with these instructions, may cause interference to other
devices in the vicinity. There is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference with other devices, which can
be determined by turning the equipment off and on, the user is encouraged to try to eliminate
the interference by one or more of the following measures:
o Reorient or relocate the receiving device.
o Increase the separation between the equipment.
o Plug the equipment into an outlet on a circuit different from that to which the other
device(s) is connected.
o Consult Customer Service or a field service technician for help.

SPECIFICATIONS FOR THIS SCALE

General
The model 500KL eye level digital beam scale uses highly sophisticated microprocessor
technology. This precision scale is designed to provide accurate, reliable and repeatable weight
measurements. In addition, each scale is designed to provide the user with features that make
the weighing process simple, fast, and convenient.
Weight can be displayed in pounds (lb) or in kilograms (kg). This scale can be powered using
AC adapter ADPT31 (USA or Canada) (not included) or ADPT30WA (international, plug
kit) (not included) or by 6 - AA batteries (included).
500KL Scale Specifications
Capacity and Resolution 500 lb x 0.2 lb (220 kg x 0.1 kg)
Power Requirements
Environmental
Physical Dimensions
DEFINITION OF SYMBOLS
Attention, Consult Accompanying Documents
Type B Applied Parts
120 - 240AC, 50 - 60Hz - 9V DC adapter (not included) or 6 - AA
batteries (included)
Operating temperatures: 50°F to 104°F (10°C to 40°C)
Storage temperatures: 30°F to 122°F (0°C to 50°C)
Maximum Humidity: 95% RH
Scale
(Overall Dimensions)
Width: 14 1/8" (359 mm)
Depth: 21 1/8" (537 mm)
Height: 53 5/8" (1362 mm)
Weight: 21 lb (9 kg)
40C Temperature range
(10°C to 40°C / 50°F to 104°F)
10C
AC to DC power supply
4
Platform
(Standing Area)
Width: 13 3/4" (349 mm)
Depth: 16 1/2" (419 mm)
Height: 2 3/8" (60 mm)
